Parts Tumbler Dyi Plans And Cnc .dxf Format Files For Plasma, Laser, Water Jet

US $11.99

Azusa, California, United States
Feb 14th

Open on mobile:
QR code

This listing is for the digital .dxf file only. .dxf format CNC cutting file Plans and dxf cutting files for DYI parts tumbler Perfect for CNC plasma/laser/water jret cutting. Your dxf file will be emailed to you shortly after payment. *This is an electronically delivered item (.dxf file via email) no physical item will be sent. The file will be sent to the email address provided to us by Paypal. Be certain your Paypal email address is up to date. After payment we will send you the digital file (see photo 2) and a link to our website where you'll find a detailed parts list, instructions, photos, and videos on how to assemble your parts tumbler from parts you collect and make using our digital CNC file. Photo of the finished item is for informational purposes only. Requires 11 ga steel and the proper CNC equipment to produce (such as a plasma, laser, or water-jet cutting machine). BACKGROUND: We plasma cut a lot of parts like steel tabs and large washers. The cheap vibrator type tumblers and roller driven tumblers were just not effective and could NOT handle the heavy steel parts so..... we designed our own heavy duty chain driven tumbler. This tumbler design was so effective that we decided to share the plans. Capacity is not officially rated, however, the tumbler is specifically designed for heavy loads. It can easily accommodate 50 large 3 inch x 3/16 steel parts (plus the de-burring media). OVER HEATING: Running your tumbler too slow may also cause overheating. Drill motors have an internal fan that needs to turn at least fast enough to exhaust the hot air from inside the drill. Check your drill for overheating and adjust the load or speed if required. Point an external fan at the drill if needed on hot days to keep the motor cool and extend the life of the drill motor. Keep the drill clean and blow it out routinely to remove any dust build-up. CHAIN ALIGNMENT: Be sure the chain engages the gears smoothly and adjust the drill mounting brackets as required to insure that the gears and chain are all properly aligned. A mis-aligned chain will tend to 'click' or even jump off the gears. TUMBLING HEAVY LOADS: We have found that when the tumbler is first loaded with a extremely heavy load, the drill may turn slowly or unpredictably until the bucket has turned several revolutions and the load has been evenly distributed. THIS IS NORMAL. Once the load has been distributed evenly the speed will even out and may increase. Adjust speed downward as needed. 60 RPM seems to work well. If you run the tumbler too fast, you'll hear the parts bumping around (like tennis shoes in the clothes dryer). When you find the correct speed you'll hear more of a constant "whooshing" sound and see a constant 'wave' inside the tumbler. WARNING: Never leave machinery operating unattended. Keep clothing, long hair, fingers, and jewelry away from moving parts. Keep pets and children away from equipment when operating. Unplug from the power source when not in use. Feel free to contact us with questions. California residents add tax. Your digital file will most likely be emailed right away but please allow up to 1 business day. Produced by Fred Nelson Fabrication. Azusa, CA

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
