Paxstarter Dip40 Microchip Development Board W/ Pic16f887 (pic16f877a) (usa)

US $16.25

Stillwater, Oklahoma, United States
Jan 29th

Open on mobile:
QR code

The PAXStarter is a great development board for beginners to experts. It is a circuit complete with everything you need to run your PIC and project! It can easily form the core of your electronic endeavors. Just plug in power and your programmer, and you're ready to start adding software. This PIC and board can easily form a simple and low cost core for your projects. And it is designed, made, and shipped quickly from the United States! This package includes a new PAXStarter DIP40 Project Development Board and a Microchip PIC16F887-I/P Microcontroller. (The PIC16F877A is the same as the PIC16F887 with added enhancements. See this side by side comparison from Microchip's website.) The board includes a 20mhz crystal, ICSP header, barrel jack power input or optional 2 pin power input header, power output for your breadboard, and more. It has everything you need to run your PIC project and connect to your ICD / PICKit so you can start coding faster. The board itself can work with many of Microchip's 40 pin DIP PICs, and it has a 40 pin socket to allow you to replace the chip as needed. (I also sell this board with the PIC18F46K22 64Mhz microcontroller mounted on board.) Project Templates / Source Code Available! I have designed some sample code projects which can provide a template for your projects. Now you can get started even faster! Basic Version: PAXStarter PIC16F887 Base Project Interrupt Driven Version: PAXStarter PIC16F887 Interrupt Driven Base Project Both of these projects use and activate the on board buttons using the internal weak pull up resistors, and they activate LEDs in different ways on PORTD to give you some output examples. They also contain all the configs necessary to run the PIC16F887. The projects were built in MPLAB X, but you can extract the code to use elsewhere. These projects also contain extensive notes explaining the why behind each step! You can get support for our code projects or for your board at our website's support forum! PIC16F887-I/P IC (Already Mounted) 20Mhz Crystal Oscillator In-Circuit Serial Programmer - ICSP Header (ICD Style) - For programming/debugging. Bypass Capacitors on Power Input, Regulator, and Output. NEW! Buttons on RB0 and RB4 for easy interrupt/program triggering. This revision also has notes and more readable lettering on the PCB itself! LED Power Indicator 2.1mm Barrel Jack Power Input Power Output Header (For Breadboard/Other Devices) Reset Button for PIC Markings for Pins Grouped by Port 40 Pin DIP IC Socket Compatible with many DIP40 Microchip PICs Grounded Mounting Holes Power Specs: Apply +7v to +18v power input through power input header or 2.1mm barrel jack On Board Linear Power Regulator: Can handle up to 1A Current If you use a barrel jack, you can draw the input voltage from the power input header pins! The power regulator's heatsink is surrounded by a connected ground plane for added heat dissipation. Note: At peak power/voltage levels, the power regulator can still get hot. Be careful when handling! 2-Pin Power Output Header on Right Side Provides +5v and Ground Programming: The 6-Pin ICSP Header, including PGM pin, can connect to an ICD style header. Note: Do not apply power through the ICSP header. Set your ICD to self power. Otherwise power could go into the wrong side of the linear regulator. Misc: Board dimensions: 81mm x 50mm Mounting holes are 3mm in diameter and centered 4mm from each corner edge. All 4 mounting holes are connected to the ground plane. The IC socket requires a chip puller to safely remove the IC. If using a different PIC, double check the pin out, voltage, and crystal speed to make sure it is compatible. A pin out map and compatibility list is at the bottom of this listing. If you have any suggestions, please let us know! Your thoughts will be added to future revisions. Please use care when handling any electronic items. Take precautions against static discharge and electrocution! We are offering a 30 day DOA/satisfaction warranty on the board. If the item does not work as advertised or expected, please let us know so we can help you! For returns or replacements, buyer is responsible for return shipping to us. We will pay for replacement shipping back to you for damaged replacements. Please double check your address! Buyer is responsible for shipping charges if an item is returned to us due to a bad address! If an item is returned to us without an RMA# within 30 days, we will automatically refund the cost of the item minus shipping. The seller (x86grl / PAX Electronics) is not responsible for any damage caused by using this board, and any warranty / refund or any other financial responsibility of any kind is limited strictly to the cost of the board itself. The buyer and/or user are responsible for the use of this board! Please do not electrocute yourself! Ask an electrician for help, especially with any high voltage or current projects! We want you to enjoy electronics -- not be hurt by them. If you have questions about this item or how to use it, please ask. We are glad to help! This board is made and shipped from the USA! For multiple items I will happily combine items to reduce shipping costs to you. If the calculated shipping amount looks too high, contact us for an accurate quote. We don't try to make money on shipping, and we don't want you to have to spend too much either. The item will be sent via USPS unless otherwise requested. The item will be sent in an anti-static bag. Please use care when handling any electronics. For International shipping, buyer is responsible for any import taxes, duties, VAT, etc. Use This Map For Programming or to Check New PIC Compatibility Vpp (ICSP) / MCLR (Reset Button): Pin 1 RA0: Pin 2 RA1: Pin 3 RA2: Pin 4 RA3: Pin 5 RA4: Pin 6 RA5: Pin 7 RE0: Pin 8 RE1: Pin 9 RE2: Pin 10 Vdd (+5V): Pin 11 Vss (GND): Pin 12 Oscillator 1: Pin 13 Oscillator 2: Pin 14 RC0: Pin 15 RC1: Pin 16 RC2: Pin 17 RC3: Pin 18 RD0: Pin 19 RD1: Pin 20 RD2: Pin 21 RD3: Pin 22 RC4: Pin 23 RC5: Pin 24 RC6: Pin 25 RC7: Pin 26 RD4: Pin 27 RD5: Pin 28 RD6: Pin 29 RD7: Pin 30 Vss (GND): Pin 31 Vdd (+5V): Pin 32 RB0: Pin 33 RB1: Pin 34 RB2: Pin 35 RB3: Pin 36 RB4: Pin 37 RB5: Pin 38 RB6: Pin 39 RB7: Pin 40 This Is a Listing of Pin Out Comatible PICs. Double Check Datasheets, Pin Out, Voltage, and Crystal Speed Requirements Before Plugging In a New PIC! PIC16F1517 PIC16F1519 PIC16F724 PIC16F727 PIC16F74 PIC16F77 PIC16F747 PIC16F871 PIC16F874A PIC16F877A PIC16F884 PIC16F887 PIC16F914 PIC16F917 PIC18F4220 PIC18F4221 PIC18F4320 PIC17F4321 PIC18F4331 PIC18F43K20 PIC18F4410 PIC18F4420 PIC18F4423 PIC18F4431 PIC18F4450 PIC18F4455 PIC18F4458 PIC18F4480 PIC18F44K20 PIC18F44J10 PIC18F4510 PIC18F4515 PIC18F4520 PIC18F4523 PIC18F4580 PIC18F4550 PIC18F4553 PIC18F4580 PIC18F4585 PIC18F45K20 PIC18F45J10 PIC18F4610 PIC18F4620 PIC18F4680 PIC18F4682 PIC18F4685 PIC18F46K20 PIC18F46K22

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	PAXStarter DIP40
Manufacturer	Pax Electronics
