Pc-base Usb Virtual 8ch Oscilloscope 2.4ms/s 12bits Programmable Generator 1008c

US $86.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

1008C Cost-effective 8 channels oscilloscope for vehicle testing; 2.4MSa/s, 12bits; DAQ card function; 8 channels programmable generator which can analog signals of crankshaft, camshaft etc. Features: 1) Vehicle Testing l First Diagnosis: Intake manifold vacuum & ignition, Petrol fumes adjusting valve vacuum & ignition, Idle exhaust ignition, Starting exhaust ignition l Ignition: primary and secondary l Sensor: Air Flow Meter, Camshaft, Crankshaft, Distributor, Lambda sensor, Throttle position l Bus Diagnosis: CAN bus data examine, CAN bus signal integrity, CAN bus LH long time acquisition, LIN bus l Performer: Petrol/Diesel l Starter and charging circuits 2) Oscilloscope l 8 channels oscilloscope, 2.4MSa/s real time sampling rate l 12 bits vertical resolution, spectrum analysis function 3) Programmable Generator l 8 channels programmable generator. l Can analog signals of crankshaft, camshaft etc. 4) Others l USB 2.0 interface plug and play, and no need extra power supply; l More than 20 types of automatic testing function, a similar interface with benchtop oscilloscope, easy to use; l Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7. Specifications: Oscilloscope Mode Vertical Analog Channel 8 Input Impedance Resistance: 1M? Input Sensitivity 10mV/div to 5V/div Input Coupling DC Resolution 12 bits Horizontal Memory Depth 4K Max. Input 400V (DC+AC Peak) Real-Time Sampling Rate 2.4MSa/s Time Base Range 1ns/div to 20000s/div(1-2-5 sequences) Time Base Precision ±50ppm Trigger Source CH1, CH2,CH3,CH4, CH5, CH6,CH7,CH8 Mode Edge X-Y Mode X-Axis Input CH1 Y-Axis Input CH2 Cursors and Measurement Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Cursors Measurement Horizontal ,Vertical, Track, Auto Measure Modes Waveform Signal Process +,- , x,?, FFT, Invert Voltage Range 10mV to 5V/div @ x 1 probe 100mV to 50V/div @ x 10 probe 10V to 5000V/div @ x 1000 probe 100V to 50000V/div @ x 10000 probe 200mV to 100V/div @ 20:1 Current Range 100mA to 50.0A/div @ CC65(20A) 1000mA to 500.0A/div @ CC65(65A) 1A to 100.0A/div @ CC650(60A) 10A to 1000.0A/div @ CC650(650A) 1A to 200.0A/div @CC1100(100A) 10A to 2000.0A/div @CC1100(1100A) Cursor Time/frequency difference, voltage difference FFT Rectangular, Hanning, Hamming, Blackman Window Math Addition, subtraction, multiplication, division Programmable Generator Channel 8 Output Level LVTTL Frequency Range 0-250kHz Interface USB 2.0 Power No need extra power supply Measurement Size 185 x 150 x 27 (mm) Weight 0.35kg Software support: Operating System: Windows NT, Windows 2000, Windows XP, VISTA, Windows 7. Note: we'll ship this item via ePacket to USA, usually the delivery time is about 2-3 weeks; For other countries, we'll ship it via registered air mail of China Post, usually the delivery time is about 30-40 days. If you want express mail service, pls contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	1008C
Sample Rate	Less than 200MSa/s
MPN	1008C
Number of Channels	8
Channels	Over 4
Country of Manufacture	China
