Pc-based Usb Oscilloscope 100mhz 2channel 250ms/s Anodised Aluminium Case 6102be

US $245.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service and epacket to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact us in advance to confirm different shipping charges before you bid. PC Based Oscilloscope Hantek6102BE Bandwidth: 100MHz, Sample Rate: 250MS/s; Standard USBXI (TM) interface, easyly inserts into USBXI (TM) housing to make up a combination instrument. Features: Excellent industrial design-the same anodised aluminium casing as iPad, which is not only beautiful and tasteful but also greatly enhanced the hardness of aluminum alloy surface, and has good heat resistance and strong wearability. Standard USBXI TM interface, easily inserts into USBXI TM housing to make up a combination instrument. USB2.0 interface, no external power source required, easy to use. Be suitable for notebook computer, product line maintenance,be used easily on business. Dimensions (mm):190(L) x100(W) x35(H), be carried easily. High performance, 250MS/s real-time sampling, 100MHz Bandwidth. Operating System: Windows 7, Windows NT, Windows 2000, Windows XP,VISTA. 23 measurement functions, PASS/FAIL Check, be suitable for technical application. Waveform average, persistence, intensity,invert,addition, subtraction, multiplication, division,X-Y plot. Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file. FFT One computer can connect many DSO, extend channel easily. LabviewVBVCDelphiC++Builder Second Design instance. Specifications Table: Input Max. sample rate Real-time sampling: 250MSa/s using one channel(Hantek6102BE) 250MSa/s using one channel(Hantek6212BE) Channels 2 Bandwidth 100 MHz analog bandwidth(Hantek6102BE) 200 MHz analog bandwidth(Hantek6212BE) Vertical Resolution 8 bits/channel (Hantek6102BE) 9 bits/channel (Hantek6212BE) Gain range Hantek6102BE 10mV ~5V/div @ x1 probe(1,2,5 sequence) 100mV ~ 50V/div @ x10 probe 1V ~ 500V/div @ x100 probe 10V ~ 5KV/div @ x1000 probe Hantek6212BE 10mV ~10V/div @ x1 probe(1,2,5 sequence) 100mV ~100V/div @ x10 probe 1V ~ 1000V/div @ x100 probe 10V ~ 10KV/div @ x1000 probe Range 8 divisions Offset level +/-4 divisions Coupling AC, DC,GND Offset increments 0.02 div Impedance 1M ohm DC accuracy +/-3% Input protection 35Vpk (DC + peak AC < 10 kHz, without external attenuation) Display Mode Y-T, X-Y and Roll Timebase Timebase range Hantek6102BE 4ns/div-1h/div(1-2-4 sequence) Hantek6212BE 2ns/div-1h/div(1-2-4 sequence) Acquisition mode Hantek6102BE Real-time sampling: 4ns/div-400ms/div. Roll mode: 1s/div-1h/div Hantek6212BE Equivalent sampling: 2ns/div ~ 4us/div Real-time sampling: 10us/div ~ 400ms/div Roll mode: 1s/div ~ 1h/div Range 10 divisions Buffer Size 10K ~ 1M Trigger Type Hantek6102BE Edge trigger Hantek6212BE Edge trigger, Pulse Trigger Mode Auto, Normal and Single

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Hantek6102BE
Sample Rate	200MSa/s - 499MSa/s
MPN	Hantek6102BE
Country/Region of Manufacture	China
Type	Digital
Number of Channels	2
Bandwidth	100MHz
Country of Manufacture	China
Channels	2
Brand	Hantek
