PC Instruments PCI-343 Single Channel Arbitrary Waveform Generator computer card, US $2100 – Picture 0
PC Instruments PCI-343 Single Channel Arbitrary Waveform Generator computer card, US $2100 – Picture 0

Pc Instruments Pci-343 Single Channel Arbitrary Waveform Generator Computer Card

US $2100

  • Canton, Georgia, United States
  • May 25th
Open on mobile:
QR code
This auction is for an arbitrary waveform generator computer board made by PC Instruments, part number PCI-343.  It is a single-channel output with additional sync output and trigger input.  It differs from the main picture in that it has only three BNC jacks, not the four pictured.  It fits into an ISA computer expansion slot.  It was made in 2001, so it is for older computers.  The card is still sealed in its original ESD bag, so it has never been used.  Included are two manuals, INSTRUMENT OPERATION AND PROGRAMMING MANUAL and WINDOWS BASED GRAPHICAL USER INTERFACE manual.  Software disks are also included, one set for BenchTop Lite SW and another set for BenchCom SW.  The disks support DOS, Windows 3.1, Windows 95, Windows 98 and Windows NT (I told you it was old). GENERIC AUCTION NOTE: Electronic devices sold AS-IS, no returns unless it does not match above description.  See description for all details.  Any and all questions please ask.  I would rather have many questions than to have you disappointed.  If you want me to perform any additional tests just let me know.  Handling time given as three days, it is usually less, but occasionally my full-time job adds a day or two.  If that is an issue let me know before purchasing the item.
