Pc-mac-linux Usb Logic Analyzer 100mhz With 64mb Memory

US $149.00

Monument, Colorado, United States
Jan 29th

Open on mobile:
QR code

Compare before you buy - our analyzers and software are BUILT IN THE USA to meet your needs - prompt shipping, clear, easy to read user instructions and fast customer support. Supports Window, Linux, and Mac platforms!! CAN (Controller Area Nework) bus * I2C, SPI, UART and parallel/serial bus setups included. FREE complex bus decoders available for MAC, Linux, and Windows: USB (USB packet decoder) CAN (Controller Area Nework) bus LIN (Local Interconnect Network) bus MDIO (Management Data I/O) protocol 1Wire (1 Wire Network) protocol Download and try the version right for you at www.chronovu.com/download/ ChronoVu offers the best price/performance package for PC based (USB) logic analyzers. This 8 bit analyzer is capable of 100MHz sample rate and contains 64Mb on-board RAM to eliminate USB transfer delays common in competing analyzers. Add to this the inclusion of canned bus setups (no extra cost for different bus protocols), data export capability, pre-trigger data collection and, Linux support and you need look no further. Try the software before you buy at www.chronovu.com. Designed and built in the USA - satisfaction guaranteed! Kit includes: ChronoVu 8bit, 100MHz logic analyzer 9 lead test probe (one ground) 9 micrograbber probes ChronoVu software CD (free download online) USB cable Quickstart install / user guide Carrying case with belt loop / shoulder strap Hardware Features 100Mhz Sample Rate Hi frequency sample rate supports applications slower analyzers can’t 8 fully independent input channels 64Mb On-board Memory On board memory means data gathering isn’t limited by USB bus transfer rate or interruptions Compact and durable design Powered through USB cable connected to your PC Software Features - New Features highlighted Linux and Mac Support User Defined Bus Setup Bus definition features allow full user programmability at no additional cost Canned Bus Setups Canned bus setups provide easy to use setups for the new user including I2C, SPI, and UART protocol FREE downloads for USB, CAN, LIN, MDIO, and 1-Wire bus decoders Timing markers on screen Easy to use mouse driven timing markers to analyze your collected data Bookmarks - once you have acquired data, place "bookmarks" at any location along the time axis to rapidly return to those locations at any time. Panning by Time - automatically scroll the data window to a specific point along the time axis or to a point that is a specific distance from the current location on the time axis. Search function - automatically scroll the data window to the location of a specific set of signal conditions or transitions. Advanced trigger options Both edge and state triggering are supported, independently, on all 16 input channels Export your collected data Acquired data can be exported to industry standard VCD file format Import data from an IEEE standard VCD (Value Change Dump) file Compare the results from two or more ChronoVu acquisitions Compare simulated results to acquired results General User Support Pre-trigger data collection allows you to see data prior to your set trigger point Setup saving allows you to save your own bus setup for future use – create your own canned setups Acquired data can be saved and reloaded for later analysis Waveform data and Bus Analysis Results can be easily viewed or printed using an intuitive user interface Comprehensive help files are available directly from the user interface and on-line Specification Value Sampling Frequency Up to 100MHz Sample Window size 8.4 Msamples per channel Acquisition trigger 8 Bit State and Edge Triggering Pre-trigger capability Yes, 262K samples per channel Signal loading ~5pF plus ~100uA state holding current Input voltage range -0.5V – 6V “Zero” logic threshold 0V to 0.8V “One” logic threshold 2V to 5.5V USB interface USB 1.1 / USB 2.0 full-speed Integrated Canned Bus Support I2C / SPI / UART(RS232) Additional free bus decoders USB, CAN, LIN, MDIO, Maxim 1-Wire User defined bus support Parallel or Serial: Synchronous, Asynchronous, or Timed

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	United States
USB logic analyzer	logic analyzer
Firmware	ChronoVu
