Pc Usb 60mhz Oscilloscope Arbitrary Waveform Generator Spectrum 4in1 Dso3064a

US $364.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you bid. PC-Based 4in1 Multifunction DSO3064A Four-in-one Pc Based Oscilloscope/Arbitrary Waveform Generator/ Spectrum Analysis/Frequency Counter. Features: Oscilloscope: 4 Channel 200MSa/s real-time sampling rate,10k—16M memory depth per Channel. Arbitrary Waveform Generator: 25MHz arbitrary waveform output,(sine wave can deliver up to 75MHz) 200MSa/s DDS,12bits of vertical resolution. Frequency Counter, FFT spectrum analysis. 8--36V Wide range of input voltage, suitable for vehicle power test. USB 2.0 interface plug and play, LAN and WIFI optional. More than 20 kinds of automatic measurement function,PASS/FAIL Check function, is suitable for engineering application. Excellent industrial design, similar interface with bench oscilloscope ,Easy to use. Software support : Windows NT, Windows 2000, Windows XP ,VISTA,Windows 7. Supply DEMO code (VC,VB,LABVIEW) and technical support. Specifications: SPECIFICATIONS DSO3064A Oscilloscope Mode VERTICAL Analog Channels 4 Bandwidth 60MHz(-3dB) Rise Time 5.8ns Input Impedance Resistance: 1M? ; Capacitance: 25 pF Input Sensitivity 10mV/div to 5V/div Input Coupling AC/DC/GND Vertical Resolution 8 bits Memory Depth 10K-16M/CH Maximum Input 400V (DC+AC Peak) HORIZONTAL Real-Time Sampling Rate 200MS/s Time BaseRange 5ns/div to 1000s/div(1-2-5 sequences) Time Base Precision +-50ppm TRIGGER Source CH1, CH2,CH3,CH4,EXT Mode Edge,Pulse,Viedo,Alternative X-Y MODE X-Axis Input CH1 Y-Axis Input CH2 Phrase Shift Max.3 degree CURSORS AND MEASUREMENT Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency,Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Cursors Measurement Horizontal ,Vertical, Track, Auto Measure Modes Waveform Signal Process +, - , x, /, FFT, Invert AUTO SET yes VOLTAGERANGE 10mV to 5V/div @ x 1 probe 100mV to 50V/div @ x 10 probe 1V to 500V/div @ x 100 probe 10V to 5000V/div @ x 1000 probe 100V to 50000V/div @ x 10000 probe 200mV to 100V/div @ 20:1 CURRENTRANGE CC65(20A),CC65(60A),CC650,CC1100 CURSOR Time/frequency difference, voltage difference FFT Rectangular,Hanning,Hamming,Blackman Window MATH Adition,subtraction,multiplication,division Arbtrory Wave Form Generator Mode Waveform Frequency DC~25MHz DAC 2K~200MHz adjustable Frequency Resolution 0.1% Channel 1CH waveform output Waveform Depth 4KSa Vertical Resolution 12 bit Frequency Stability <30ppm Wave Amplitude +-3.5V Max. Output Impedance 50 ? Output Current 50mA Ipeak=50mA System BW 25M Harmonic Distortion -50dBc(1KHz), -40dBc(10KHz) INTERFACE USB 2.0(Lan ,WIFI Optional) POWER SOURCE 8--36V Wide range of input voltage,suitable for vehicle power test MECHANICS Volume 255 x 190 x 45 (mm) Weight 1Kg

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DSO3064A
Channels	4
MPN	DSO3064A
Sample Rate	200MSa/s - 499MSa/s
Type	Digital
Number of Channels	4
Bandwidth	60MHz - 99MHz
Country of Manufacture	China
