Peak Dca75 Atlas Advanced Semiconductor Analyser From Japan New

US $158.80

Saitama, Japan
Feb 12th

Open on mobile:
QR code

Peak Electronic Design Limited Description Peak DCA75 Atlas Advanced Semiconductor Analyser From Japan New ATLAS DCA75 PRO The set includes Body, AAA alkaline batteries (body already set), Micro USB cable (about 1m), USB memory (dedicated software collecting) The DCA75 Pro supports all the components that the popular Peak Atlas DCA55 supports, but adds plenty more. Components supported include: • Transistors (including Darlingtons), Silicon and Germanium types. • MOSFETs, enhancement mode and depletion mode types. • JFETs, including normally off SiC types. • IGBTs (insulated gate bipolar transistors). • Diodes and Diode networks. • LEDs and bicolour LEDs (2 lead and 3 lead types). • Zener Diodes with measurement of zener voltage up to 12V. • Voltage regulators (measures regulation voltage, drop-out voltage, quiescent current). The instrument can be used stand-alone or connected to a PC. Either way, the DCA Pro will automatically identify the component type, identify the pinout and also measure a range of component parameters such as transistor gain, leakage, MOSFET and IGBT threshold voltages, pn characteristics and much more. Curve Tracing When connected to a PC using the supplied USB cable, a range of curve-tracing functions can be performed. Many predefined and user-adjustable graphs are available: • Bipolar transistor output characteristics, Ic vs Vce. • Bipolar transistor gain vs collector current. • Bipolar transistor input characteristics, Vbe vs Ib. • Bipolar transistor saturation characteristics, Vce(sat) vs Ic. • MOSFET transfer function, Id vs Vgs. • JFET transfer function, Id vs Vgs. • PN junction I/V curves, forward and reverse options (for Zener diodes). • Zener slope resistance curves, Zr vs Ir All curve-tracing data can be instantly pasted into Excel© for further graphing and analysis. Test voltages of up to ±12V and test currents of ±15mA are available for analysing components. These values are kept deliberately low to prevent the accidental damage to potentially unknown components. Manufacturer : PEAK ELECTRONIC Package weight : 0.254 kg RoHS : conform Condition:NEW Payment ?We accept PayPal only. ?We can ship ONLY to your Paypal address. ?Make sure that your shipping address is up to date on your paypal account before going through the transaction. ?Please pay within 3 days after the auction closed. Shipping Ship to Registerd SAL. Until the arrival to the product is 2 - 4 weeks on average. Your order will be shipped within 3~4 business days (excluding Saturday, Sunday, and Japan's Holiday) after the payment is confirmed. We need this handling time for special international secure packaging and paperwork. Under certain circumstances it may exceed this period, then you will be informed any unexpected shipping delay. ?Please note that delivery delays occur due to your country's custom. ?We are going to pack your item carefully, and ship immediately. (1) EMS (Standerd Shipping) ?Express Mail Service, with insurance and tracking number ?EMS is fast and the safest method of shipping. ?We highly recommend EMS. Shipping Duration Shipping Method Asia North America Central America Middle East AU, NZ Europe Russia South America Africa (2) Registerd SAL Economy Shipping 2 - 4 weeks 2 - 4 weeks 2 - 4 weeks 2 - 4 weeks (1) EMS Standerd Shipping 3 - 6 days 3 - 6 days 3 - 6 days 4 - 7 days About Us Customer satisfaction is important for me. Please contact me, when there is a question. We will answer that question in good faith. International Buyers - Please Note: ?Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. ?Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying. ?These charges are normally collected by the delivering freight (shipping) company or when you pick the item up - do not confuse them for additional shipping charges. ?We do not mark merchandise values below value or mark items as “gifts” - US and International government regulations prohibit such behavior. Thank you for looking at my page (^O^)/ Copyright © 2013 vonziris7bless. All rights reserved.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Peak Electronic Design Limited
Model	DCA75
