Pelco Cm9760-mda Master Time-date Title Distribution Amplifier 16 Inputs Sg36

US $830

Rhinelander, Wisconsin, United States
Mar 4th

Open on mobile:
QR code

PELCO CM9760-MDA Master Time-Date Title Distribution Amplifier 16 Inputs Pulled from working environment. Powers Up and light comes on, but I don't have the equipment to test this further. So it is sold for parts NO RETURNS. Product Features • Master Time-Date Titler • Distribution Amplifier • Accepts Master Time-Date Strings from CM9700 Series Systems • Stand-alone Use, with Keyboard Programming • Provides Master Time-Date and Title for up to 63 Slave Units (64 Total Units) • Accepts Text Messages (RS-232/RS-422) from Third-Party Systems for Insertion onto any Video Channel • 16 Ground-Isolated Video Inputs per Unit • 4 Video Outputs per Input • Outputs Selectable for Time-Date Only, Time-Date and Title, or No Character Generation • Includes Video Amplification • Line Compensation • Includes Easy-to-Use Windows® Programming Package The CM9760-MDA is a master distribution amplifier that inserts time-date and a programmable title of up to 24 characters on 1-16 video signals. Each of the sixteen video inputs has four fully independent video outputs. Each video output is selectable to include or exclude time-date and title generation. Each of the 16 video inputs is individually programmable. Programming includes individual camera titles and cable compensation for up to 1,500 feet (457 m) of RG59/U coaxial cable. Characters are adjustable horizontally and vertically on-screen with digital brightness control. Time-date information is common among all channels. All characters are white with black outline to provide maximum viewing efficiency in a variety of background conditions. All inputs are individually ground isolated to prevent ground loops. The CM9760-MDA can act as a stand-alone time-date and title generator or can be synchronized to a CM9700 Series system as a matrix time-date and title generator. As a stand-alone unit, the CM9760-MDA can be addressed to provide the master time-date for up to 63 slave units. When connected to a CM9700 Series system, multiple MDAs can have synchronized time-date with all CM9700 Series system components. (The CM9760-CDU-T must be used when more than 16 MDAs are required.) The MDA supports RS-232, RS-422, and RS-485 communication on both input and output ports. In addition, the CM9760-MDA can accept text messages via RS-232/RS-422 from third-party systems. A message can consist of up to 24 characters, and multiple messages can be displayed simultaneously on up to five display lines. The messages can be inserted onto any video channel independently. A simple, easy-to-use Windows® program is provided for initial setup of camera titles and all other MDA features. The CM9760-KBD, KBD200A or KBD300A keyboard may be used instead of the Windows program for on-screen programming. Battery back-up protects programming information for a minimum of one year. MODELS CM9760-MDA Master distribution amplifier with time-date and title, 120 VAC, 60 Hz CM9760-MDA-X Same as CM9760-MDA except 230 VAC, 50 Hz RELATED PRODUCTS CM9760-CDU-T Code Distribution Unit; 16-channel RS-422 transmit only (2-wire and ground). Required for use in configurations having more than sixteen CM9760-MDAs. ELECTRICAL Input Voltage CM9760-MDA 120 VAC, 60 Hz CM9760-MDA-X 230 VAC, 50 Hz Power Consumption 25 W Fuse 120 V: 250 mA 230 V: 125 mA MECHANICAL Connectors Video Input BNC (16) Video Output BNC (4 per input; 64 total) Communications In RJ-45 Out RJ-45 VIDEO Video Input(s) .5 to 2 Vp-p, 16 inputs per unit Video Output(s) 1 Vp-p, 4 outputs per input Input/Output Impedance 75 ohms, terminated Gain Unity ±1 dB Frequency Response ±1 dB at 8 MHz Bandwidth ±3 dB at 15 MHz Crosstalk -60 dB at 3.58 MHz Gain +.88 dB +.55 dB with 1,500 feet RG59/U Video Coaxial Cable Requirements RG59/U 750 feet (229 m) RG6/U 1,000 feet (305 m) RG11/U 1,500 feet (457 m) Video Coaxial Cable Compensation Range (Inputs Only) 0-1,500 feet (using RG59/U cable) Selectable ranges: – None – 500 feet (152.4 m) – 1,000 feet (304.8 m) – 1,500 feet (457.2 m) Differential Gain Less than 1% Differential Phase Less than 1/2° Maximum Output Level 1.0 Vp-p terminated Signal-to-Noise Ratio -45 dB Tilt Less than 1% Inputs Ground isolated Character Size 7 x 9 TV Lines Brightness Individually adjustable (digital) Position Individually adjustable (digital) COMMUNICATION Type RS-232, RS-422, RS-485 Data Rate Selectable; 1200, 2400, 4800 or 9600 baud Cable Requirements 24-gauge shielded twisted pair RS-232 Maximum 50 feet (15.25 m) RS-422 Maximum 4,000 feet (1,219 m) RS-485 Maximum 4,000 feet (1,219 m) GENERAL Construction Aluminum Dimensions 5.25" H x 19.00" W x 12.90" D (13.21 x 48.26 x 32.77 cm) Mounting Fits 19-inch EIA Standard rack mount (3 RUs) Operating Temperature 32° to 120°F (0° to 49°C) Humidity 10% to 90%, non-condensing Memory Backup Lithium battery Unit Weight CM9760-MDA 13.52 lb (6.13 kg) CM9760-MDA-X 13.12 lb (5.95 kg) Shipping Weight CM9760-MDA 20 lb (9.06 kg) CM9760-MDA-X 20 lb (9.06 kg) CERTIFICATIONS/RATINGS • CE, Class B (CM9760-MDA-X) • FCC, Class B (CM9760-MDA) • Meets NEMA Type 1 standards Check out my other items! Please Fully Read our Policy If it's NOT in the picture, or in the description, then it will NOT be included in this sale. This applies to power cords, cables, manuals and A/C adapter!. If you experience a problem Please contact us FIRST! We strive to do our best to work with customers to resolve issues. All of our auctions include notes on the condition of the item (it may require cables or plugs or even more components to function). If it is not in the picture it is Not included. We do stand behind what we sell. We never intentionally sell defective products unless it is stated as such in the auction (DOA, for repair or parts). If you have a problem with a product, please contact us right away (within 14 days). If an item is listed as "AS-IS" then it is simply that, "AS-IS" and can't be returned. There will be no refunds of any kind on AS-IS items. If auction says "parts or repair" the item is NOT Functioning properly, item is described as best as we can, and has No Returns No Refunds. We acquire our equipment from reliable sources. Many of our items are tested in-house. Some items are not tested, either because we trusted the source of the equipment based on their history with us, or because we are unable to test the equipment (this would be because we do not have proper equipment to test or lack of knowledge in the product itself). Although we welcome your questions and inquiries, bidders are expected to do their own research in regard to the compatibility and/or software/driver requirements for any item they are considering purchasing. In most cases, all information that we have available to us is included in the text of the auction. Any other questions email us or call! Thanks! Payment and Shipping We accept PayPal and ship mainly USPS Priority mail daily Monday-Friday at out location - holidays and weekends excluded. Sometimes there are exceptions and delays but we try hard to get your item shipped as soon as possible, average is 2 business days after payment. If you make payment on Friday it will not ship out until Monday. We will send you tracking and it will post to the auction as well when package is sent. Hawaii, Alaska, APO/FPO, and PR customers - We can ship by USPS PRIORITY MAIL only. Please ask for a quote S&H (Shipping and Handling charge) represent the actual cost of shipping, packing material, and labor only. Non-USA International Customers: For international shipping please ask for a quote generally USPS. Insurance is required on most item's. Any item valued over $99.99 requires express shipping. Any International customs charges VATS that may be added by the shipping company are the responsibility of the buyer. This Includes all customs charges! Many countries have a Value Added Sales Tax VAT, which is charged when an item crosses into their border. VAT is charged in addition to applicable duties. It's the buyer's responsibility to know how much tax and duties will be charged. We will not declare your package as a gift. Return Policy Returns or Refunds - You must contact us within 14 day of receiving the item! Buyer will be responsible for all return shipping fees! Restocking Fee: Please make sure this is the item you need. On most working items, we cannot guarantee compatibility with your equipment or software. If you have any doubt, or need more information, please visit the manufacturer's web site or call their customer service before placing your bid. On top of return shipping cost there is a small restocking fee for returning an item that is not defective and bought in error or not in original condition. Service You Can Trust We are only human and we make mistakes some times. If you experience a problem Please contact us FIRST! We strive to do our best to work with customers to resolve issues. Still need help? Have a question? Contact us through the eBay auction messaging system. Shop and Save - We Combine Shipping for most items!

“Pulled from working environment. Powers Up and light comes on, but I don't have the equipment to test this further. So it is sold for parts NO RETURNS.”

Type	Control Panels & Keypads
Model	Master Distribution Amplifer
Brand	Pelco
MPN	CM9760-MDA
Connectivity	Closed System/CCTV-Wired
Country/Region of Manufacture	United States
