Pelco Kbd300a Ptz Controller Universal Keyboard

US $160

Boulder City, Nevada, United States
Jun 23rd

Open on mobile:
QR code

I am not a dealer but rather a private user thinning out camera surveillance, cameras and lens no longer in operation. Although used, my equipment has been well maintained. If you have questions, please send a message. Ask questions prior to purchasing. No sales tax. Model Number: KBD300A Serial Number: 407-8136 Date Code: 05286 Version: 5.70 Electrical Requirements: 12 Volts, 50/60 Hz, 1.5 Watts Retail Price: $629.95 Condition: Used, removed from service General Description: The KBD300A Keyboard is a full-function, desktop keyboard controller that can be used in a variety of applications. A barrel-type joystick provides precise pan and tilt control of fixed-speed and variable-speed receivers. Twisting the joystick clockwise or counterclockwise zooms the lens in or out. Keys select cameras and monitors; operate presets, patterns, auxiliaries, and sequences; open and close the iris; zoom and focus the lens; and start and stop auto, frame, and random scanning. The keyboard can be used in three modes of operation: CM6700 Mode, CM6800 Mode, and Direct Mode. The KBD300A Keyboard automatically recognizes the mode. In the first two modes, the keyboard is plugged into a CM6700, CM6800, or CM9760-SAT Switcher/Controller Unit (SCU) and is used to program and operate the SCU. The maximum number of keyboards per unit is eight (CM6700 and CM6800-32X6), sixteen (CM6800-48X8, CM6800E-48X8, and CM6800-96X16) or four (CM9760-SAT). In CM6700/CM6800 applications, the keyboard can control cameras connected directly to the SCU or through an MX4000 Series Genex Multiplexer. If you do not need all the features of the CM6700/CM6800 SCU, but want the same keyboard functionality, then one keyboard can be wired directly to camera receivers in Direct Mode (KBDKIT required). Up to 16 receivers can be wired to a keyboard; however, a switcher such as an MS500 or VA6100, is required to route video to the monitor. Direct Mode uses two-wire control of receivers using Pelco’s P protocol. Features: Keyboard to Control: CM6700/CM6800/CM9760-SAT Matrix Switchers - Genex® Multiplexer When Used with CM6700 and CM6800 Up to 16 Receivers Directly from Keyboard (such as Spectra® And Esprit®) Automatically Recognizes Modes of Operation Joystick Control of PTZ Functions Preset Position and Pattern Control Auxiliary Operation Auto/Random/Frame Scanning Programming of CM6700/CM6800/CM9760-SAT/CM9760-MDA
