PH-3515F Mitutoyo Optical Comparator w/QM Data, Edge, Stand, & Surface Illuminat, US $10000 – Picture 0
PH-3515F Mitutoyo Optical Comparator w/QM Data, Edge, Stand, & Surface Illuminat, US $10000 – Picture 0

Ph-3515f Mitutoyo Optical Comparator W/qm Data, Edge, Stand, & Surface Illuminat

US $10000

  • Palatine, Illinois, United States
  • Jun 14th
Open on mobile:
QR code
Mitutoyo PH-3515F Optical Comparator Package Mitutoyo's PH-3515F is a heavy-duty, bench-top optical comparator that uses a horizontal optical system. This optical comparator includes an 8” x 4” floating-type workstage that incorporates linear scales for fast, accurate measurement. The workstage provides high accuracy and can handle a workload of up to 100 lbs. The PH-3515F offers a 14" diameter screen that includes cross-hairs for easy alignment and an erect image on Day-bright screen. The Edge Detection option for the QM-Data that is included with this package makes for more accurate and more repeatable measurements. The Edge Detection system uses a fiber optic sensor that recognizes edges on your parts when the stage is moved, regardless of the operator that is using the machine. A wide range of accessories are also available for the PH-3515F making it suitable for a wide variety of applications. Package Includes the following... Main Unit 10X Lens QM-Data 200 Digital Display Edge Detection Surface Illumination Optical Comparator Stand Free USA Freight FREE On-Site Installation & Initial Calibration Mitutoyo PH-3515F Brochure... Click here QM-Data 200 Brochure... Click here Free Freight Anywhere in continental USA Free On-Site Installation / Initial Calibration
