Phase-a-matic Static Phase Converter - Model Pam-1200hd

US $325.00

Palmdale, California, United States
Jan 29th

Open on mobile:
QR code

** PHASE CONVERTER** 8 TO 12 HP HEAVY DUTY SERIES PHASE-A-MATIC MODEL PAM-1200HD LIST FOR $370.00 For light to moderate loads; for motor loads only. Runs most motors at 2/3 rated HP. Where applied appropriately, it's the workhorse of many home shop machines - and much more. HEAVY DUTY Static Phase Converters should be used: Lathes above 3hp not fitted with a clutch. Air compressors; the motor diameter pulley must also be reduced by 1/3, or a 50% larger motor can be fitted. Long heavy starting cycles, frequent starting, instant reversing (as in rigid tapping), or unattended motors or equipment. If jogging is required, or if there is a good chance of the motor being stalled during use. PHASE-A-MATIC™ Static Phase Converters have been developed, tested, and thoroughly proven over a 43 year period demonstrating exceptionally high reliability and long life. These converters are the workhorse of many commercial uses and multitudes of home shop machines. LIFE EXPECTANCY: The Static Converter has been in use for approximately 43 years and has already proven itself to be extremely reliable when properly applied. Phase-A-Matic™ was recently able to purchase back the first one that was ever sold, and it is still working fine. It is reasonable to expect the converter to be in good working condition and service for 20 or 30 years or more. We continue to hear back from customers who have them still running their equipment faithfully after 20 years and more. Uses include: Lathes, Mills, Grinders, Drills, Saws, Metalworking and Woodworking Equipment, Printing Equipment, Sewing Machines, Garbage Disposals, Food Processing Equipment, Meat Grinders, Food Mixers and Blenders, Conveyer Belts, and numerous other uses. STATIC CONVERTER APPLICATION NOTES Please read the application notes before ordering if you are unsure. CLICK HERE FOR OTHER SIZES ________________________________________________________ METHOD #1 Using the PHASE-A-MATIC™ Static Converter only will produce approximately 2/3 normal HP.* This method is inexpensive, the most popular, provides excellent results on most machines tools and numerous other uses. Motor speed is not changed. Most two-speed motors, power feeds, coolant pumps, etc., will operate normally. Motor will instant reverse. There is nothing to change. All switch gear will work normally. Refers to wye-wound motors; delta-wound motors will run at 50% rated HP. Delta-wound motors are very rare in the USA, occasionally being found on some imported equipment, and are particularly found on German and Italian machines. ________________________________________________________ METHOD #2 FOR FULL OR CLOSE TO FULL HP ~~ Configure as a rotary converter using Phase-A-Matic™ static unit ~~ Full or close to full HP can usually be obtained by running a three-phase motor and PHASE-A-MATIC™ Static Converter combination as shown on the installation instructions. When running unloaded, the windings of the motor function as a rotary transformer or generator while consuming very little extra power. The idler motor needs to be at least 50% larger than the largest motor that you want to run to accommodate the higher starting current. A good quality 3600 RPM, three phase wye-wound, 220V motor is the best choice. 1800 RPM motors can be used on applications not heavily loaded. Used three-phase motors are inexpensive and readily available. When using this method, it is possible to run multiple machines as long as the idler motor is large enough to handle the largest load it would ever have at any one time. For instant reversing of the load motor, as in rigid tapping, the idler motor must be a minimum of twice the HP rating of the load motor, and perhaps more. The Static Converter is sized to the HP of the idler motor, not the load motor(s). ________________________________________________________ Availability: Orders are typically processed within 24-hours after payment is received in full. For any special requests lead times may vary. Shipping: Freight charges are the responsibility of the purchaser. We try to ship it the safest and least expensive way we can. We will also use your shipper if you would like. To obtain a quote for shipping, email me your city, state and zip code and whether you are residential or commercial. I will send you an estimate asap. If you would like more information, contact me at 803-327-2121 and ask for Charlie or just dial extension 221. FOR MORE INFO. CALL 803-327-2121 ASK FOR CHARLIE VISIT OUR EBAY STORE FOR OTHER PRODUCTS Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Apr-04-09 at 05:16:13 PDT, seller added the following information:

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Electrical Equipment Type

Phase Converters
