Phase Failure Phase Sequence Protect Relay 3 Phase Electronic Protection

C $15.38

CHINA, China
Mar 1st

Open on mobile:
QR code

Phase Failure Phase Sequence Protect Relay 3 Phase Electronic Protection Description Phase Failure Phase Sequence Protect Relay Specifications 220-380VAC 460-660VAC 50Hz/60Hz A.Characteristics of protection: 1.Phase loss protection: It means that any phase occurs phase loss when the protected circuit is in running or stopping status. In this case, the red indicator light will be lighted and be priority. 2. Phase opposite protection: It is a safeguard acting immediately, which protects L1, L2, and L3 three phase against wrong connection sequence. In this case, the yellow indicator light will be lighted. 3. Voltage imbalance protection: While a protection of voltage imbalance rate > 8%, the imbalance of three phase voltage will affect the safe running of the equipment. In this case that there is a phase losing, the red indicator light will be lighted and be priority. 4. Delay protection:When the fault happens, the monitor will delay 1~2 seconds to act and release. B. Characteristics of performance: 1. The protection functions of relay don’t be affected by current intensity of circuit or load, impulse current, imbalance current and load characteristic. The relay could long term work under full capability and full climate. Power consumption is lower than 2W. C. Characteristics of working: 1.If the connection of L1, L2 and L3 phases are right, the green light of the relay illuminates and the relay closes. If they are wrong, the yellow light of the relay illuminates. Exchanging any two of them, the relay will accept the phase sequence and begin to work normally. In this case that there occurs yellow light illuminated and relay unclosed after the protected equipment works normally, it should be a wrong connection of external circuit. The relay has a function of protection against wrong connection. 2. While any of these L1, L2 and L3 phases is Na phase, the red light is lighted with the unlighted green light and the released relay. While the voltage come back to normal, it will recover immediately with lighted green light and closed relay. 3. L1, L2 and L3 connect with three phase AC. NO, COM are normally open contact point and NC, COM are normally closed contact point. Use lead to connect terminal directly. Package Content ONE Phase Failure Loss Sequence Relay 3 Phase Electronic Protection Payment Only through PayPal Delivery details Item will be shipped within 2 working days after receipt of cleared payment. - EMS, DHL Express delivery: Normal postage time is 5 to 7 days to United States, Canada, United Kingdom, Australia, New Zealand, Major Asian Countries, and West Europe.( We have to ask for you contact No. for Express delivery and this may increase the handling time.) - Standard Flat Airmail deliverys: Normal postage time is 15 to 20 days to United States, Canada, United Kingdom, Australia, New Zealand, Major Asian Countries, and West Europe. Combined Shipping Condition To avoid any inconvenience and disputes, we don't accept combined orders in principle. Terms of sales - For DOA (Defective on Arrival) item, please notify us to obtain a merchandise return code and shipping instruction. Then, send it back within 7 days upon date of receipt. Return shipping costs will be at your expenses. - We only accept the returned item with full packaging materials without being used. After receiving your returned item, it will take 7 days for evaluation and investigation. A brand new replacement unit will be sent to you at our shipping costs if unit is proved to be defective. - Please NOTE: We don't accept returns via any EXPRESS SERVICES (Including: EMS, UPS, FedEx, and DHL etc.) - Buyer pays for returns. If it is proved as defect item, we will refund the return postage based on the bill issued by posts. All returns via express service will be refused, unless the buyer pay for the duty. Other Terms Customs would be less likely to impose taxes/duties on a small parcel. However, it will be at your expenses if incurred. Insurance is included in the Shipping & Handling costs you paid. Contact and Communications If you have any problems in pre-sale, shipping and after-sale questions, you can reach us by eBay message Furthermore, welcome to your inquiries and further contacts About us We hope you enjoy the shopping in our store.Your satisfaction is my priority. If you have any questions please let me know. I will make effort to provide timely response and do my best to make you satisfied! Contact us Please contact us via eBay message if you have any question. Engineered for professional eBay sellers!
