PHASE II Dividing Plates (Fits 8", 10"&12"Only), US $169.99 – Picture 0
PHASE II Dividing Plates (Fits 8", 10"&12"Only), US $169.99 – Picture 0

Phase Ii Dividing Plates (fits 8", 10"&12"only)

US $169.99

  • Flushing, New York, United States
  • Jan 30th
Open on mobile:
QR code
PHASE II Dividing Plates (Fits 8", 10"&12"Only) Applications Use for indexing, drilling or milling. Machining curved surfaces by utilizing circular milling. Milling and boring where close tolerances are required. Machining flat surface is set at a certain angle to a given reference. Quality control. Jig boring. Features Adjustable satin chrome dials are extremely large in diameter for easy reading. All dials are precision ground and graduated in minute and second increments as well as degrees. Totally enclosed rugged base casting, precision ground and parallel within .0006". (2) Locks provided for positive action. The worm and shaft are of one piece hardened and ground. All rotary tables are equipped with disengageable worms which affords quick rotation for indicating workpieces. Oiling facilities are provided for all moving parts. Low profile. TurntableMade of "high grade meehanite castings". Precision ground and parallel within .0006". All T-Slots are machined. Graduations are accurately cut in increments of one degree. 3 Morse Taper hole in center bore. Benefits A convenient method of worm adjustment is provided to compensate for wear. Each table is supplied with a signed inspection certificate and an operating certificate.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Manufacturer Part Number 241-101
Part Brand PHASE II
