Phidget Vint ±40v Voltage Input Module

US $27.50

Swanton, Vermont, United States
Aug 11th

Open on mobile:
QR code

Description Can be used to measure voltages up to ±40V You can select the voltage range (±5V, ±15V or ±40V) in software Automatic mode adjusts the range based on present voltage measurements Isolated for stability When a 0-5V voltage input isn't enough, the Phidget VINT ±40V Voltage Input Module can be used to measure voltages up to ±40V. You can select the voltage range (±5V, ±15V or ±40V) in software; a smaller range results in higher precision. This Phidget also has an automatic mode that continuously adjusts the range based on present voltage measurements, so you'll always have the most accurate measurement possible. This Phidget is electrically isolated, so a power surge on the circuit you're measuring will not damage your VINT Hub or your computer. Isolation also improves stability by eliminiating potential ground loops. Specifications Sensor Properties Sensor Type: Voltage (DC) Board Properties Controlled By: VINT Voltage Sensor Withstand Voltage Max: ± 50 V DC Number of Voltage Inputs: 1 Sensor Input Impedance: 1 MΩ Voltage Difference Max: ± 40 V DC Sampling Interval Min: 40 ms/sample Sampling Interval Max: 60 s/sample ±5V Range Voltage Resolution: 200 μV DC Voltage Offset Max: 5 mV DC Measurement Error Max: 0.2 % Voltage Noise: 3 mV DC ±15V Range Voltage Resolution: 500 μV DC Voltage Offset Max: 15 mV DC Measurement Error Max: 0.2 % Voltage Noise: 10 mV DC ±40V Range Voltage Resolution: 1.2 mV DC Voltage Offset Max: 40 mV DC Measurement Error Max: 0.2 % Voltage Noise: 25 mV DC Electrical Properties Current Consumption Max: 11 mA Physical Properties Recommended Wire Size: 16 - 26 AWG Operating Temperature Min: -40 °C Operating Temperature Max: 85 °C

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Phidgets
MPN	Does not apply
Type	Phidgets
UPC	Does not apply
