Phidgets Advanced Servo Controller 8-motor

US $97.75

Swanton, Vermont, United States
Jul 16th

Open on mobile:
QR code

Description Phidgets Advanced Servo Controller Can drive up to eight servo motors Lets you control the position, velocity, and acceleration Connects to your computer via USB Operates from 8 to 30 VDC Uses a voltage of 5, 6 or 7.4 V The Phidgets Advanced Servo Controller allows you to control the position, velocity, and acceleration of up to 8 RC servo motors. It requires a 8-30 VDC external power supply; its switching power supply allows the RCC0004 to efficiently operate from 8 to 30 VDC and can be used with a wide range of batteries. You can control the regulator and choose a global servo voltage of 5, 6 or 7.4 Volt. A servo will have more torque when running at a higher voltage, but will have a shorter overall lifespan. The Phidgets Advanced Servo Controller can drive up to eight servo motors. Each of the servo motors plugs directly to the board with no extra cables or soldering required. Servos come in two major varieties: limited rotation and continuous rotation. With limited rotation servos, the motor has a limited range of motion, but can be precisely controlled within that range. A continuous rotation servo can rotate continuously, but you won't be able to tell the servo to move to a specific location in degrees; instead you'll specify a direction and speed and for it to rotate at. Specifications Servo Controller Number of Motor Ports: 8 Pulse Width Resolution: 83.3 ns Pulse Code Period Max: 25 ms Board Controlled By: USB (Mini-USB) API Object Name: RCServo Electrical Properties Supply Voltage Min: 8 V DC Supply Voltage Max: 30 V DC Current Consumption Max: 26 mA Continuous Motor Current Max: (per motor) 1.6 A Surge Current Max: (per motor) 3 A Output Impedance (Motor): 600 O Output Motor Voltage: 5 V DC USB Speed: Full Speed Physical Properties Power Jack Polarity: Center Positive Recommended Wire Size: 12 - 24 AWG Object Temperature Min: 0 °C Object Temperature Max: 70 °C What's Included Hardware mounting kit: 4 x M3 Bolts (2 cm length) 4 x Plastic spacers (5 mm length) 4 x M3 Nuts Dimensions Servo Controller Pulse Width Min: 83.3 ns Pulse Width Max: 2.7 ms Physical Properties Power Jack Hole Diameter: 5.5 mm Power Jack Pin Diameter: 2.1 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Phidgets
Type	Phidgets
MPN	Does not apply
UPC	Does not apply
