Phoenix Contact Tp 07t Hw/fw 02/120.0 Touch Panel (windows Ce 5.0)

US $1185

Hilliard, Ohio, United States
Jun 3rd

Open on mobile:
QR code

New old stock. Requires 24v DC power supply. Touch panel with 17.8 cm/7" TFT-Display (Resistive industrial touch screen), 800 x 480 Pixel (WVGA), 65536 colors, ARM9™, 200 MHz, 2x USB Host 2.0, 1 x Ethernet (10/100 Mbps), RJ45, Windows CE 5.0 and User software: Visu+ / AX OPC Server. (Bus system: without) Dimensions External dimension, width 203 mm External dimension, height 147 mm External dimension, depth 5 mm Note regarding external dimension Dimensions of the front plate Installation dimension, width 195 mm Installation dimension, height 139 mm Installation dimension, depth 54 mm Back to top Display Display 17.8 cm/7" TFT Screen resolution 800 x 480 Pixel(s) (WVGA) Backlighting LED Display backlight MTBF > 50000 h Touch technology Resistive industrial touch screen Colors 65536 colors Back to top Computer data Processor ARM9™, 200 MHz Operating systems Windows® CE 5.0 User software Visu+ AX OPC Server RAM 64 MB SDRAM Mass storage 32 MByte flash memory Network 1 x Ethernet (10/100 Mbps), RJ45 Interfaces 2x USB Host 2.0 Bus system without Back to top General Mounting type Front installation Back to top Ambient conditions Degree of protection IP65 (front), IP20 (back) Ambient temperature (operation) 0 °C ... 50 °C Ambient temperature (storage/transport) -25 °C ... 70 °C Permissible humidity (operation) 20 % ... 85 % (non-condensing) Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing) Vibration (operation) DIN EN 60068-2-6 Shock DIN EN 60068-2-27
