Pi C-842.40: 4-axis Dc Motor Controller Pc Card W/bracket Card & User Guide

US $1,250.00

Zicron Ya'akov, Israel
Jan 30th

Open on mobile:
QR code

PI C-842.40: 4-Axis DC Motor Controller PC Card w/Bracket Card & User Guide Available complementary items sold separately: PI 3493 CPU Board PI Optical Broad-IR Range F206B0002 PI Digital controller frame (F-206.B0002) w/power/CPU/SW PI C-842.40 Description: The C-842 PC plug-in DC motor controller board is the optimal solution for applications where a multi-axis precision positioner is to be computer controlled by a PC. Integrated low noise, linear amplifiers allow operation of micro positioning systems with motor/gear head drives without additional external amplifiers, reducing costs and simplifying the set-up.The C-842 employs a fast DSP (Digital Signal Processor) providing high performance PID motion control with many options of trajectory generation and filter setting. Position, velocity, acceleration and several other motion parameters can be programmed individually for each axis on-the-fly. The C-842 can be installed in 16-bit ISA PC slots. Any quadrature TTL incremental encoder can be used for position feedback (linear scales and rotary encoders, interferometers). Eight TTL inputs and eight TTL outputs are available for flexible automation (trigger functions etc.). The C-842 offers full access to the internal processor functions via the I/O address space. Programmers can use hex commands and 32 bit parameters for very fast communication (3000 data/sec). The motor controller also comes with a variety of software tools such as LabViewa drivers, libraries in C, PASCAL and BASIC and a DOS program for instant, easy operation without low-level programming. Windowsa programming is supported by 32 bit and 16 bit DLLs. ISA Bus Compatible Simultaneous Control of up to 4 DC Servo Motors Fast 32 bit Digital PID V-ff Servo Loop On-Board Linear Power Amplifiers (12 bit) and PWM Outputs Trapezoidal-Curve, S-Curve & Velocity Contouring LabViewa Drivers, Libraries for C, PASCAL, etc. Programming Tools for Win 95, NT, 3.1 and DOS Hardware Interrupts for Process Control High Level Command Language Interface 16 I/O Lines for Flexible Automation 12 TTL Inputs for Limit & Origin Switches Electronic Gearing Programmable Torque Limit

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Tested. Excellent working condition!Complementary PI broads also available!”
