Pic Development Learning Board Kit + 16*2 Lcd + 16f877a

US $110

shenzhen, China
Jun 9th

Open on mobile:
QR code

PIC 16F87X Microcontroller Development Board 2 ( Brand new ) The development board can be used for all PIC16XX/PIC18XX 28PIN or 40PIN PIN devices (except 16 F59) Ideal for the Student or Hobbyist to start developing and testing your PIC projects with this multi-featured and flexiable PIC Development board. PIC 16F87X Development board 2 consists of : 8 indicator LEDS ICD2 Header connector for programming / Debugging with Microchips ICD2 16x2 LCD Character display 6 Seven segment display RS232 Serial communication port 16 button matrix Keypad Stepp motor slot 4 push buttons Infrared reception DB9 connector and RS232 Transeiver (for serial Comms) I2C Serial EEprom 24c01B - dipswitch used for write enable and setting device address (on supported eeproms) 2 pin sockect for main Osc (4MHz resonator -Default) allows for easy changing of the main Osc frequency. Provion for loading caps if using a crystal. Buzzer Reset switch Uncommited PIC I/O ports - So the PIC's I/O lines may be connected to any of the onboard modules or external circuits onboard power regulator (accepts 9 - 12v AC/DC supply) 4*4 Matrix keyboard – to test password lock and other items. Buzzer voice/PWM output experiment – to practice normal voice, music and PWM output sound. 5-way independent key-press–for easy various key-press input experiments. RS232 serial communication – to realize the communication between SCM and computer. Infrared remote-control receiver – to practice infrared remote-control decoding and all kinds of infrared remote control. All I / O output to facilitate expansion IIC (I2C) communication – to read/write 24CXX series chips with hardware IIC or software IIC directly. SPI communication–to read/write EEPROM of 93CXX with hardware SPI or software analog SPI,to select 8-bit or 16-bit read/write method through jumper. Clock selection – jumper for switch between various oscillation modes, to replace crystal vibration of different frequency as required by development of product. DS18B20 digital temperature sensor – 1-wire bus communication, wide range for temperature measurement, high accuracy and sensitivity (remark:chip DS18B20 is optional). Stepper motor driver circuit (remark:Stepper motor is optional). Simulation debugging interface – to directly connect ICD1/ICD2/MCD1/MCD2 and carry out on-line simulation for on-board chips and resources On-board power module – can connect to the polarity of external AC or DC power supply optionally, voltage range 7-12V mcu/mpu reset key 1-way A/D converter signal input. 8-way independent LED 12864-character LCD–128*64 lattices.(remark:12864- character LCD is optional). 1602-character LCD–internal 5*7 lattices, to display 16*2-character. 6-bit 7-segment digital tube – to realize dynamic or static display experiment of digital tube, to display clock,temperature or to make counter. Board Resource Introduction 1) All pins are taken out on IDC36 connectors to make them available for further connections. 2) 40P/28P chip socket 3) Power module 4) ICD2 connector for debug and program 5) RS-232 communication for connection with a PC or any other device with a DB9 connector. 6) Digital thermometer DS1820 for temperature measurement from -55°C to 125°C. 7) SPI communication module 8) IIC communication module 9) LCD12864 and 1602 LCD module 10) Potentionmeters for simulating analog voltage input 11) Reset circuit. 12) 4*4 matrix keyboard module 13) Remote control receiver & decoder module 14) 6bit 7-segment display module 15) 8 LEDs are provided. 16) Stepper motor Driver module 17) Beeper module 18) External interrupt input module 19) Independent button module The auction includes PIC 16F87X Microcontroller Development Board RJ-12 TO RJ-12 ICD ICSP cable RS232 Cable 16F877A Chip 1602 LCD CD-ROM (PCB Layout,Board Schematic,Sample code (C / ASM) for each onboard module, MPLAB 7.50 .) Power supply(110-240 AC TO 9V DC) Sample with C and ASM Program sources code as below (using PIC16F877A): DS1820 Buzzer 128x64 GLCD (See the following Photos) 1602 LCD (See the following Photos) 93C46 24C02 4x4 Key testing 8x LED 7x segment ADC Infrared Remote stepp motor Weight : 820g Package Size: 290mm*220mm*80mm Worldwide shipping by Registered Air Mail--(It also have Tracking Numbe for sending) FAQ Hi, if we buy now, when you shipped to me ? When we received you payment, we will sent the items to you within 1-2 work days ! you sent the items to me ,you have the tracking number for me ? We will send you by Registered Air mail, This is have tracking number, and it can takes 15-20 working days. If the item in the swap in the transport stolen, and you will be re-distributed to us? If you buy the parts, within the prescribed time did not receive goods, we will re-sent to you, please do not give us EBAY negative to me, For example, if you buy the parts on jaunary 1, you will received the parts on Jaunary 30 before, becuase it takes15-20 working days, if you not received the parts on Jaunary 30 before, please tell me we, we will re-sent to you! We WON'T resend any bounce back order due to incorrect shipping address payment method Accept paypal only Credit card through Paypal I will ship to the shown address on you PAYPAL Payment notice. Please confirm your shipping address in the PayPal Account Please tell me you phone number Buyers need to absorb ALL re-shipments fee of returned packages Return Policy 100% money back guarantee or exchange the same class of the products. Full refund will be issued upon receipt of the Deffective Item. Please be advised that shipping and handling cost are not refundable. Buyers must be returned the defective products within 7 days from the date when product received. Refund or Replacement will be sent after we received your returning item. Any missing parts / damages must be you contact us in ebay message within 7 days after you have receive the item. In all cases, buyers pay shipping at their own cost to return products for exchange or refund. Shipping Schedule Normally, Your order will be shipped within 1-2 our business days after the payment is cleared. The shipping time may vary, depends on receiver's location. Item Declare Your item will mark as Gift or Sample and a low's value. We are NOT responsible for any import tax, customs fees or customs delay. Buyer cannot request to cancel the auction or request for refund under this situation. Please check with your local tax authorities BEFORE bidding. However, most of our items can reach to buyers without any taxes.
