Pic40 Diy Prototyping Kit For 40 Pin Microchip Pic Microcontrollers Fks

US $12.77

Shanghai, China
Jan 29th

Open on mobile:
QR code

PIC40 Prototyping Kit for 40 Pin Microchip PIC Microcontrollers for DIY Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge This PIC40 prototyping kit for 40 pin microchip PIC controllers is a top quality, double sided PTH 1.6mm fiberglass board which combines a large prototyping area with pads on both sides. Features: Large prototyping area with pads on both sides of the board 5V power supply is selectable from the on-board 5V regulator, the microchip ICD2 or USB +5V and 0V power rails are extended along top and bottom edges for easy access On-board RS232 level converter buffers the PIC UART to/from the 9 pin D connector 9 pin D connector is tracked for connection to a PC serial port RTS and CTS lines are buffered and brought to CN9 RS232 interface is disconnectable from the PIC using jumper links in CN6 USB socket is disconnectable from the PIC using jumper links in CN6 5 pin programming header is provided to allow for in-circuit programming from other programmers such as the MELABS serial or USB programmers 470nf USB capacitor is disconnectable from the PIC using CN7 The PIC40 prototyping kit for 40 pin microchip PIC controllers is brand new and boxed and comes with connection diagram and link to the manufacturer's website for further instruction and information 40 Pin Microcontrollers Include: 16F877; 18F452; 18F4520; 18F4550 (the kit also allows for easy prototyping of the USB part) It is buyer's responsibility to contact us within 14 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. All items MUST be returned in their original condition. Buyer is responsible for shipping and proof of delivery on all returns. We aim to achieve a 5 stars rating for each and every transaction. If you are not 100% satisfied, PLEASE don't leave a neutral or negative feedback or low 1, 2 DSR before you contact us for help. Also please note that due to the recent Air Cargo Security Alerts, there may be delays totally outside our control. Your purchase will be shipped via standard airmail, which normally takes 7-20 working days to reach you. We also offer express shipping, which normally takes 4-7 working days to reach you. You should expect to pay any amount, if there is any, charged by the government in your respective country; this includes (and is not limited to) duties & taxes. We accept PayPal only. inkfrog terapeak i000000 On Nov-28-14 at 19:57:49 PST, seller added the following information:
