Description Microchip's PICkit3 In-Circuit Debugger/Programmer uses in-circuit debugging logic incorporated into each chip with Flash memory to provide a low-cost hardware debugger and programmer. The MPLAB PICkit3 allows debugging and programming of PIC? and dsPIC? Flash microcontrollers at a most affordable price point using the powerful graphical user interface of the MPLAB Integrated Development Environment (IDE). The MPLAB PICkit3 is connected to the design engineer's PC using a full speed USB interface and can be connected to the target via an Microchip debug (RJ-11) connector (compatible with MPLAB ICD 2, MPLAB ICD 3 and MPLAB REAL ICE). The connector uses two device I/O pins and the reset line to implement in-circuit debugging and In-Circuit Serial Programming?. Features Full-speed USB support using Windows standard drivers Real-time execution Processors run at maximum speeds MPLAB IDE compatible (free copy included) Built-in over-voltage/short circuit monitor Firmware upgradeable from PC/web download Totally enclosed Supports low voltage to 5 volts (1.8v to 5.0v range) Diagnostic LEDs (power, active, status) Read/write program and data memory of microcontroller Erase of all memory types (EEPROM, ID, configuration and program) with verification Freeze-peripherals at breakpoint Program up to 512K byte flash with the Programmer-to-Go Basic Debugger System The debugger system can be configured to use standard ICSP communication for both programming and debugging functions. CAUTION: Do not change hardware connections while the PICkit3 or target is powered. Supported Devices Refer to MPLAB IDE v8.76, the following devices are supported: ICSP PIC10F PIC10F200, PIC10F202, PIC10F204, PIC10F206, PIC10F220, PIC10F222 PIC12F PIC12F508, PIC12F509, PIC12F510, PIC12F519, PIC12F609, PIC12HV609, PIC12F615, PIC12FHV615PIC12F629, PIC12F635, PIC12F675, PIC12F683 PIC16F PIC16F505,PIC16F506,PIC16F526,PIC16F54,PIC16F57,PIC16F59,PIC16F610,PIC16FHV610,PIC16F616, PIC16FHV616PIC16F627, PIC16F628, PIC16F627A, PIC16F628A, PIC16F648A, PIC16F630, PIC16F631, PIC16F636,PIC16F639,PIC16F676,PIC16F677,PIC16F684,PIC16F685,PIC16F687,PIC16F688,PIC16F689, PIC16F690,PIC16F72, PIC16F73, PIC16F74, PIC16F76, PIC16F77, PIC16F722, PIC16F723, PIC16F724, PIC16F726, PIC16F727, PIC16F716,PIC16F737, PIC16F747, PIC16F767, PIC16F777, PIC16F785, PIC16FHV785,PIC16F84A,PIC16F87,PIC16F88,PIC16F818,PIC16F819,PIC16F870,PIC16F871,PIC16F872, PIC16F873, PIC16F874,PIC16F876, PIC16F877, PIC16F873A, PIC16F874A, PIC16F876A, PIC16F877A, PIC16F882, PIC16F883, PIC16F884, PIC16F886, PIC16F887,PIC16F913, PIC16F914, PIC16F916, PIC16F917, PIC16F946, PIC16F1933, PIC16F1934, PIC16F1936, PIC16F1937,PIC16F1938, PIC16F1939, PIC16LF1933, PIC16F1934, PIC16F1936, PIC16F1937,PIC16LF1938, PIC16LF1939 PIC18F PIC18F242, PIC18F252, PIC18F442, PIC18F452,PIC18F248, PIC18F258, PIC18F448, PIC18F458 PIC18F1220, PIC18F1320, PIC18F2220, PIC18F2320,PIC18F1230, PIC18F1330,PIC18F2221, PIC18F2321 PIC18F2331, PIC18F2410, PIC18F2420, PIC18F2431,PIC18F2423,PIC18F2450, PIC18F2455, PIC18F2458, PIC18F2480,PIC18F2510, PIC18F2515, PIC18F2520, PIC18F2523,PIC18F2525,PIC18F2550, PIC18F2553, PIC18F2580, PIC18F2585,PIC18F2610, PIC18F2620, PIC18F2680,PIC18F2682, PIC18F2685,PIC18F4220, PIC18F4221,PIC18F4320, PIC18F4321, PIC18F4331,PIC18F4410, PIC18F4420, PIC18F4423,PIC18F4431, PIC18F4450, PIC18F4455,PIC18F4458, PIC18F4480,PIC18F4510, PIC18F4515, PIC18F4520, PIC18F4523 PIC18F4525, PIC18F4550, PIC18F4553, PIC18F4580,PIC18F4585,PIC18F4610, PIC18F4620, PIC18F4680 PIC18F4682, PIC18F4685,PIC18F6310, PIC18F6390, PIC18F6393,PIC18F6410, PIC18F6490, PIC18F6493 PIC18F6520, PIC18F6525, PIC18F6527, PIC18F6585,PIC18F6620, PIC18F6621, PIC18F6622, PIC18F6627 PIC18F6628, PIC18F6680,PIC18F6720, PIC18F6722, PIC18F6723PIC18F8310, PIC18F8390, PIC18F8393 PIC18F8410, PIC18F8490, PIC18F8493,PIC18F8520, PIC18F8525, PIC18F8527, PIC18F8585,PIC18F8621, PIC18F8620,PIC18F8622,PIC18F8627,PIC18F8628,PIC18F8680,PIC18F8720,PIC18F8722,PIC18F8723,PIC18F24J10, F25J10, F44J10, F45J10,PIC18LF24J10, LF25J10, LF44J10, LF45J10,PIC18F24J11, F25J11, F44J11, F45J11 PIC18LF24J11, LF25J11, LF44J11, LF45J11,PIC18F26J11, F46J11,PIC18LF26J11, LF46J11,PIC18F24J50, F25J50, F44J50, F45J50,PIC18LF24J50, LF25J50, LF44J50, LF45J50,PIC18F26J50, F46J50,PIC18LF26J50, LF46J50 PIC18F63J11, 63J90, 64J11, 64J90PIC18F65J10, 65J11, 65J15PIC18F65J50, 65J90PIC18F66J10, 66J11, 66J15, 66J16,PIC18F66J50, 66J55, 66J60, 66J65,PIC18F66J90,PIC18F67J10, 67J11, 67J50, 67J60,PIC18F67J90,PIC18F83J11, 83J90, 84J11, 84J90,PIC18F85J10, 85J11, 85J15, 85J50,PIC18F85J90,PIC18F86J10, 86J11, 86J15, 86J16,PIC18F86J50, 86J55, 86J60, 86J65,PIC18F86J90,PIC18F87J10, 87J11, 87J50, 87J60,PIC18F86J90,PIC18F96J60, 96J65,PIC18F97J60, PIC18F13K22, LF13K22, F14K22, LF14K22PIC18F13K50,14K50,PIC18F23K20,24K20,25K20,26K20PIC18F43K20, 44K20, 45K20, 46K20 PIC24F PIC24F04KA200, 04KA201,PIC24F08KA101, 08KA102,PIC24F16KA101, 16KA102,PIC24FJ16GA002, 16GA004,PIC24FJ32GA002, 32GA004,PIC24FJ32GA102, 32GA104,PIC24FJ32GB002, 32GB004,PIC24FJ48GA002, 48GA004,PIC24FJ64GA002, 64GA004,PIC24FJ64GA102, 64GA104,PIC24FJ64GB002, 64GB004,PIC24FJ64GA006, 64GA008, 64GA010,PIC24FJ64GB106, 64GB108, 64GB110,PIC24FJ96GA006, 96GA008, 96GA010,PIC24FJ128GA006, 128GA008, 128GA010,PIC24FJ128GA106, 128GA108, 128GA110,PIC24FJ128GB106, 128GB108, 128GB110,PIC24FJ192GA106, 192GA108, 192GA110,PIC24FJ192GB106, 192GB108, 192GB110,PIC24FJ256GA106, 256GA108, 256GA110,PIC24FJ256GB106, 256GB108, 256GB110 ,PIC24HJ12GP201, 12GP202,PIC24HJ16GP304,PIC24HJ32GP202, 32GP204,PIC24HJ32GP302, 32GP304 ,PIC24HJ64GP202, 64GP204,PIC24HJ64GP206, 64GP210, 64GP506,PIC24HJ64GP502, 64GP504, 64GP510 ,PIC24HJ128GP202, 128GP204,PIC24HJ128GP206, 128GP210, 128GP306,PIC24HJ128GP310,PIC24HJ128GP502, 128GP504,PIC24HJ128GP506, 128GP510,PIC24HJ256GP206, 256GP210, 256GP610 dsPIC30 dsPIC30F1010,dsPIC30F2010, 2011, 2012,dsPIC30F2020, 2023,dsPIC30F 3010, 3011, 3012 dsPIC30F3013, 3014,dsPIC30F4011, 4012, 4013,dsPIC30F5011, 5013, 5015, 5016,dsPIC30F6010A, 6011A, 6012A dsPIC39 dsPIC39F6013A, 6014A, 6015 dsPIC33 dsPIC33FJ12GP201, 12GP202,dsPIC33FJ16GP304,dsPIC33FJ32GP202, 32GP204,dsPIC33FJ32GP302, 32GP304 dsPIC33FJ64GP202, 64GP204,dsPIC33FJ64GP206, 64GP306, 64GP310,dsPIC33FJ64GP706, 64GP708, 64GP710 dsPIC33FJ64GP802, 64GP804,dsPIC33FJ128GP202, 128GP204,dsPIC33FJ128GP206, 128GP306, 128GP310, dsPIC33FJ128GP706, 128GP708, 128GP710,dsPIC33FJ128GP802, 128GP804,dsPIC33FJ256GP506, 256GP510, 256GP710 dsPIC33FJ06GS101, 06GS102, 06GS202,dsPIC33FJ16GS402, 16GS404,dsPIC33FJ16GS502, 16GS504 dsPIC33FJ12MC201, 12MC202,dsPIC33FJ16MC304,dsPIC33FJ32MC202, 32MC204,dsPIC33FJ32MC302, 32MC304 dsPIC33FJ64MC202, 64MC204,dsPIC33FJ64MC506, 64MC508, 64MC510,dsPIC33FJ64MC706, 64MC710,dsPIC33FJ64MC802, 64MC804,dsPIC33FJ128MC202, 128MC204 dsPIC33FJ128MC506, 128MC510,dsPIC33FJ128MC706, 128MC708, 128MC710 dsPIC33FJ128MC802, 128MC804,dsPIC33FJ256MC510, 256MC710 dsPIC32 PIC32MX320F032H, 320F064H,PIC32MX320F128H, 320F128L,PIC32MX340F128H, 340F128L,PIC32MX340F256H PIC32MX340F512H,PIC32MX360F256L, 360F512L,PIC32MX420F032H,PIC32MX440F128L, 440F128H PIC32MX440F256H,PIC32MX440F512H,PIC32MX460F256L, 460F512L 11 Series Serial EEPROM Devices 11LC/AA010,11LC/AA020,11LC/AA040,11LC/AA080,11LC/AA160 24 Series Serial EEPROM Devices 24LC/AA/C00,24LC/AA01B, 02B, 04B, 08B,24LC/AA16B, 32A,24LC/AA/FC64, 128, 256, 512,24LC/AA/FC1025 25 Series Serial EEPROM Devices 25LC/AA010A, 020A, 040A,25LC/AA080A, 080B, 160A, 160B,25LC/AA320A, 640A,25LC/AA128, 256, 512, 1024 93 Series Serial EEPROM Devices 25LC/AA/C46A, 46B, 46C,25LC/AA/C56A, 56B, 56C,25LC/AA/C66A, 66B, 66C,25LC/AA/C47A, 76B, 76C ,25LC/AA/C48A, 86B, 86C MCP250xx CAN Devices MCP25020, 25025,MCP25050, 25055 Debugger To Target Communication Connecting the PICkit3 to the target board through standard ICSP interface using 6-pin connector. The programmer connector pinout is shown in the figure below: PICkit3 Status LEDs The Status LEDs indicate the status of the PICkit3. Power (green) – Power is supplied to the PICkit3 via the USB port. Active (blue) – The PICkit3 has connection to the PC USB port and the communication link is active. Status: Busy (yellow) – The PICkit3 is busy with a function in progress, such as programming. Error (red) – The PICkit3 has encountered an error. Package Contains PICkit3 x 1 USB type A to Mini-B cable x 1 6-pin ICSP cable x 1 Can I get a tracking number for my package? Yes,We will provide a tracking number for all the customers. Terms and Conditions Payment: PayPal is the only method of payment that we accept. Shipping: 1.Please confirm your address in paypal, including your Phone number!. 2.All items will be shipped within the HANDLING TIME on receipt of cleared payment and We ship items to Worldwide. 3.To USA:via ePACKET Express Shipping,it usually takes 8-15 working days to receive. 4.To Taiwan,Macao and Hongkong:via SF-Express,it usually takes 1-4 working days to receive. 5.To South America:via HONGKONG post,SWISS POST,UK POST,China Post or Singapore POST,it usually takes 15-45 working days to receive. 6.To Europe:Germany/Belgium/China Post,it usually takes 6-15 working days to receive,but there may be some delay to some countries. 7.To others Countries:via HONGKONG/SWISS/UK/China/Singapore POST,it usually takes 10-35 working days to receive. 5.We also provides FAST shipping,like DHL,UPS,feDEX and EMS.Pls tell me if you want to use them,and i will send paypal invoice for fast-shipping fee to you. It usually takes 4-9 workig days to receive.And pls contact us firstly. ePACKET(only for American Customers):www.usps.com UK Post:http://www.royalmail.com China Post:http://intmail.183.com.cn/ HongKong Post: www.hongkongpost.com Swiss Post: http://www.swisspost.com Singapore Post:http://www.singpost.com Germany Post: https://www.deutschepost.de Belgium Post: www.bpost.be DHL:www.dhl.com UPS:www.ups.com feDEX:www.fedex.com EMS:www.ems.com.cn Returns Policy: 1.We are happy to return any unused item in its original packaging within 14 days of delivery. 2.Buyers are responsible for the round (two-way) shipping cost. Feedback: 1.We'll leave POSITIVE FEEDBACK on receipt of cleared payment. 2.If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. 3.Once any problems occured, please contact us first. We'll try our best to work things out.Don't leave your BAD feedback without any communication. Some useful websites for the local tracking(Usually available after the package reach the Destination Country) Belgium www.bpost.be Argentina www.correoargentino.com.ar/consulta_envios/track.php HongKong www.hongkongpost.com Armenia www.haypost.am/view-lang-eng-page-79.html United Kingdom http://track.royalmail.com/ Korea http://service.epost.go.kr/iservice/ems/ems_eng.jsp Singapore www.singpost.com Denmark http://www.postdanmark.dk/contentfull.dk?lang=en Japan www.japanpost.jp Spain http://www.correos.es/ENG/13-MenuRec2/01-MenuRec21/2010_c1-LocalizadorE.asp USA www.usps.com Turkey http://www.ptt.gov.tr/en/interaktif/kayitliposta-yd.php Switzerland www.swisspost.ch/ Qatar http://www.imolink.net/qpost/ttchmail/tracktrace.htm Croatia http://ips.posta.hr/ Lebanon http://www.libanpost.com.lb/TrackTrace/tabid/59/Default.aspx Moldova www.posta.md:8081/ Belarus http://www.belpost.by/info/ems-search-packages-mail/ The United Arab Emirates www.emiratespost.com Ecuador http://ipsweb.correosdelecuador.com.ec/ipswebtracking/tracking.htm Indonesia http://ems.posindonesia.co.id/ Portugal http://www.ctt.pt/fectt/wcmservlet/ctt/landingpage.html Norway www.posten.no/en/ Finland http://www.posti.fi/english/eservices/itemtracking/index.html Sweden www.posten.se/ India http://ipsweb.ptcmysore.gov.in/ipswebtracking/ Greece www.elta-net.gr/ Iceland http://www.postur.is/english/desktopdefault.aspx/tabid-69/ Hungary www.posta.hu/ Russia http://www.russianpost.ru/rp/servise/ru/home/postuslug/trackingpo Australia www.auspost.com.au/track/ Ireland http://track.anpost.ie/track/tracklist.html Austria www.post.at/en/track_trace.php New Zealand http://www.nzpost.co.nz/Cultures/en-NZ/OnlineTools/Tracking/ Bangladesh www.bangladeshpost.gov.bd/ Canada http://www.canadapost.ca/cpo/mc/languageswitcher.jsf Peru www.serpost.com.pe/ Israel www.israelpost.co.il/itemtrace.nsf/mainsearch?openform&L=EN Chile www.correos.cl/seguimiento/ Uruguay www.correo.com.uy/index.asp?codPag=tyt Poland www.sledzenie.poczta-polska.pl/ Malta http://trackandtrace.maltapost.com/TrackAndTrace.asp Italy http://www.poste.it/ Ukraine www.ukrposhta.com/www/upost_en.nsf/search_post?openpage Mexico www.sepomex.gob.mx/ Lithuania http://trace.post.lt/tandtCritImbed.jsp?refresh=1276154675419 Kazakhstan http://portal.kazpost.kz/ Armenia www.haypost.am/view-lang-eng-page-79.html Bosnia and Herzegovina http://www.bhp.ba/track/1/0/36.html Estonia http://teavitus.post.ee/ar_status.asp Jordan http://213.186.163.148/ipswebtrack/ Latvia http://www2.pasts.lv/lv/uzzinas/meklet_sutijumu.html Germany www.deutschepost.de Saudi Arabia www.sp.com.sa/English/Saudipost/Pages/default.aspx Luxembourg www.trackandtrace.lu/homepage.htm Slovenia http://sledenje.posta.si/default.aspx Singapore www.singpost.com/ra/ra_article_status.asp Cyprus http://ips.cypruspost.gov.cy/ipswebtrack Slovakia http://tandt.posta.sk/en Bulgaria http://services.bgpost.bg/WebTracking Romania www.posta-romana.ro/track_trace Brazil http://www.correios.com.br/sistemas/rastreamento/
