Pico Technology Picoscope 2207a Usb Oscilloscope

US $592.00

Waconia, Minnesota, United States
Jan 29th

Open on mobile:
QR code

Pico Technology PicoScope 2207A USB Oscilloscope Visit our online store for all of your Electronic Test and Measurement Tools Needs - www.shop.northtreeassociates.com The Pico Technology PicoScope 2200A Series Oscilloscopes - Like a benchtop oscilloscope - only smaller and better. Up to 200 MHz bandwidth 1 GS/s sampling Advanced digital triggers Arbitrary waveform generator Serial decoding USB powered Ultra compact design Included with the purchase a PicoScope 2200A Series Oscilloscope: • PicoScope 2200A Series oscilloscope • USB cable • Two x1/x10 passive probes • Quick Start Guide • Software and reference CD Pico Technology PicoScope 2207A USB Oscilloscope Specifications Oscilloscope - Vertical Model PicoScope 2207A Bandwidth 100MHz Rise Time (calculated) 3.5ns Input Channels 2 Vertical Resolution 8 Bits Enhanved Vertical Resolution Up to 12 Bits Input Ranges ±50 mV, ±100 mV, ±200 mV, ±500 mV, ±1 V, ±2 V, ±5 V, ±10 V, ±20 V Input Sensitivity 10mV/div to 4V/div (10 vertical divisions) Input Characteristics BNC, 1M? || 13pF Analog Offset Range (vertical position adjustment) ±250 mV (50 mV to 200 mV ranges) ±2.5 V (500 mV to 2 V ranges) ±20 V (5 V to 20 V ranges) DC Accuracy +- 3% of full scale Overvoltage Protections +- 100V (DC+AC peak) Oscilloscope - Horizontal Maximum Sampling Rate 1 Channel 2 Channel 1 GS/s 500MS/s Equivalent Sampling Rate (ETS) 10 GS/s Maximum Sampling Rate (continuous streaming mode) 9.6MS/s Timebase Ranges 1ns to 5000s/div Buffer Memory 40kS Buffer Memory (streaming mode) 100 MS per channel in PicoScope software Waveform Buffer Normal Triggering Rapid Block Triggering Up to 10,000 waveforms Up to 32 Waveforms Tmebase Accuracy +-50ppm Sample Jitter <5 ps RMS Dynamic Performance (typical) Crosstalk (full bandwidth) Better than 400:1 (equal ranges) Harmonic Distortion <-50dB at 100kHz, full-scale input SFDR >52dB at 100kHz, full-scale input Noise <200uV RMS (+-50mV range) Bandwidth Flatness (at scope input) (+0.3 dB, -3dB) from DC to full bandwidth) Triggering Sources Channel A, Channel B Trgger Modes None, auto, repeat, single, rapid (segmented memory) Advanced Triggers Edge, window, pulse width, window pulse width, dropout, window dropout, interval, logic. Trigger Types, ETS Rising or falling edge Trigger Sensitivity Digital triggering provides 1 LSB accuracy up to full bandwidth. In ETS mode, typical 10mV p-p at full bandwidth Maximum Pre-Trigger Capture 100% of capture size Maximum Post-Trigger Delay 4 billion samples Trigger Re-Arm Time < 2 µs on fastest timebase Maximum Trigger Rate Up to 32 waveforms in a 64 ?s burst Function Generator Standard Output Signals Sine, square, triangle, DC voltage, ramp, sinc, Gaussian, half-sine Psuedorandom Output Signals White noise, PRBS Standard Signal Frequency DC to 1 MHz Sweep Modes Up, down, dual with selectable start/stop frequencies and increments Output Frequency Accuracy +- 50ppm Output Frequency Resolution <0.01 Hz Output Voltage Range +-2 V Output Adjustments Any amplitude and offset within +-2V range Amplitude Flatmess (typical) <0.5 dB to 1MHz DC Accuracy +-1% of full scale SFDR >60dB @ 10kHz full-scale sine wave Connector Type Front panel BNC with 600? output impedance Overvoltage Protection +- 10V Arbitrary Waveform Generator Update Rate 2 MS/s Buffer Size 4 Ks Resolution 12 Bits Bandwidth >100 kHz Rise Time (10% to 90%) <2µs Spectrum Analyzer Frequency Range DC to 100 MHz Display Modes Magnitude, peak hold, average Window Types Rectangular, Gaussian, triangular, Blackman, Blackman-Harris, Hamming, Hann, flat-top Math Channels Functions –x, x+y, x–y, x*y, x/y, x^y, sqrt, exp, ln, log, abs, norm, sign, sin, cos, tan, arcsin, arccos, arctan, sinh, cosh, tanh, freq, derivative, integral, min, max, average, peak, delay Operands A, B (input channels), T (time), reference waveforms, constants, Pi Automatic Measurements Scope Mode AC RMS, true RMS, cycle time, DC average, duty cycle, falling rate, fall time, frequency, high pulse width, low pulse width, maximum, minimum, peak to peak, rise time, rising rate. Spectrum Mode Frequency at peak, amplitude at peak, average amplitude at peak, total power, THD%, THD dB, THD plus noise, SFDR, SINAD, SNR, IMD Statistics Minimum, maximum, average and standard deviation Serial Decoding Protocols CAN, LIN, I2C, UART/RS-232, SPI, I2S, FlexRay Mask Limit Testing Statistics Pass/fail, failure count, total count Display Interpolation Linear or sin(x)/x Persistance Modes Digital color, analog intensity, custom, or none General PC Connectivity USB 2.0 (USB 1.1 and 3.0 compatible) USB cable included Power Requirements Powered from USB port Dimensions 142 x 92 x 19mm Weight <0.2 kg (7 oz) Temperature Range Operating: 0 °C to 50 °C (20 °C to 30 °C for stated accuracy). Storage: –20 °C to +60 °C Humidity Range Operating: 5% to 80% RH non-condensing. Storage: 5% to 95% RH non-condensing. Safety Approvals Designed to EN 61010-1:2010 Compliance RoHS, WEEE, and LVD compliant. Tested to meet EN61326-1:2006 and FCC Part 15 Subpart B. Software Included PicoScope 6, Windows and Linux SDK, example programs (C, Visual Basic, Excel VBA, LabVIEW) PicoScope Software PC Requirements Microsoft Windows XP (SP3), Windows Vista, Windows 7 or Windows 8 (not Windows RT). 32- or 64-bit Language (manual) English Language (software interface) English

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Pico Technology
Type	Analog & Digital
Model	PicoScope 2207A USB Oscilloscope
Bandwidth	100MHz
Make	Pico Technology
Channels	2
MPN	PicoScope 2207A
Sample Rate	1 GS/s
