Pico Technology Picoscope 4223 Automotive Usb Oscilloscope 2 Channel Starter Kit

US $863.36

Waconia, Minnesota, United States
Jan 29th

Open on mobile:
QR code

Pico Technology PicoScope 4223 Automotive USB Oscilloscope 2 Channel Starter Kit Visit our online store for all of your Electronic Test and Measurement Tools Needs - www.shop.northtreeassociates.com When you buy a Pico Technology PicoScope Automotive Oscilloscope you get industry-leading performance that is both affordable and easy-to-use. Pico Technology PicoScope automotive oscilloscopes combine the performance and features you would expect from the market leader in PC oscilloscope technology, all in an easy-to-use and affordable package. Use with any vehicle 2 or 4 channels Up to 80 MS/s real-time sample rate Up to 20 MHz bandwidth Up to 32 M sample buffer memory 100 V maximum input No power supply required USB 2.0 (USB 1.1 compatible) connection for fast screen updates Protected against overloads and short circuits Includes PicoScope Automotive software Free software updates 24 month warranty Free technical support Each Pico Technology PicoScope 4223 Automotive USB Oscilloscope 2 Channel Starter Kit Includes: Premium test leads 2 20:1 attenuator 1 Flexible backpinning probe (red) 1 Flexible backpinning probe (black) 1 Multimeter probe (red) 1 Small crocodile/gator clip (black) 1 Small crocodile/gator clip (red) 1 Battery Clip (Red) 1 Battery Clip (black) 1 Automotive software CD-ROM 1 Training resources DVD 1 Automotive Quick Start Guide 1 USB cable 1.8m 1 Pico Technology PicoScope Automotive Scopes Specifications Oscilloscope Specifications Variant PicoScope 4223 PicoScope 4423 Bandwidth 20 MHz (10 MHz on ±50 mV range) Channels 2 4 Vertical resolution 12 bits Enhanced vertical resolution 16 bits Accuracy ±1% Sensitivity 10 mV/div to 20 V/div Input ranges (full scale) ±50 mV to ±100 V in 11 ranges Input characteristics 1 M? in parallel with 22 pF Input type Single-ended, BNC connector Input coupling Software selectable AC/DC Overload protection ±200 V on single input Maximum sampling rate (single shot) 1 or 2 channels in use 3 or 4 channels in use 80 MS/s 20 MS/s Buffer memory 32 M samples shared between active channels Waveform buffer Up to 1000 waveforms Timebase ranges 100 ns/div to 200 s/div Triggers Source Any input channel Basic triggers Auto, repeat, single, none Advanced triggers Rising edge, falling edge, edge with hysteresis, pulse width, runt pulse, dropout, windowed Maximum pre trigger delay 10 x “per division” timebase setting Maximum post trigger delay 50 s Spectrum Analyser Bandwidth 20 MHz Frequency range DC to 20 MHz Display modes Magnitude, peak hold, average PC Requirements Minimum Processor: Pentium II processor, or equivalent Memory: 64 MiB (XP) / 512 MiB (Vista) / 1 GiB (Win 7) minimum Operating system: 32 or 64-bit edition of Microsoft Windows XP SP2, Vista or Windows 7 Ports: USB 2.0 compliant port Recommended Processor: 2 GHz Pentium IV processor, or equivalent Memory: 256 MiB (XP) / 1 GiB (Vista / Win 7) Operating system: 32 or 64-bit edition of Microsoft Windows XP SP2 (or above), Vista or Windows 7 Ports: USB 2.0 compliant port Environmental Operating environment Temperature range 0 °C to 45 °C (15 °C to 40 °C for quoted accuracy) Storage environment Temperature range Humidity -20 to +60°C 5 to 95% RH, non-condensing Physical Dimensions Dimensions 200 x 140 x 35 mm (approx 7.9 x 5.5 x 1.4 in) Weight <500 g (approx 1.1 lb) General Additional hardware (supplied) USB 2.0 cable, user manuals, software CD-ROM PC interface USB 2.0 (USB 1.1 compatible) - cable supplied Power requirements Powered from USB port Compliance FCC (EMC), CE (EMC and LVD), RoHS compliant Warranty 2 years

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Pico Technology
Bandwidth	20MHz
Model	PicoScope 4223 Automotive Oscilloscope Starter Kit
Channels	2
MPN	PicoScope 4223 Automotive 2 Channel Starter Kit
Sample Rate	80 MS/s
Type	Analog & Digital
Make	Pico Technology
