Picosecond Pulse Labs 5509 2.92mm DC BLOCK 7 kHz to 50 GHz ( Agilent ) - 5.1ps, US $270.00 – Picture 0
Picosecond Pulse Labs 5509 2.92mm DC BLOCK 7 kHz to 50 GHz ( Agilent ) - 5.1ps, US $270.00 – Picture 0

Picosecond Pulse Labs 5509 2.92mm Dc Block 7 Khz To 50 Ghz ( Agilent ) - 5.1ps

US $270.00

  • Saint Paul, Minnesota, United States
  • Feb 13th
Open on mobile:
QR code
Picosecond Pulse SMA DC Block The PSPL5509 DC Block is an ultra-broadband inner conductor DC block with a flat frequency response over many decades up to 50 GHz. It is available in a choice of 2.92 mm or 2.4 mm connectors.  KEY PERFORMANCE SPECIFICATIONS From 7 kHz to 50 GHz Bandwidth 5 ps Rise time 1 dB Insertion Loss to 40 GHz The following figure shows the Insertion Loss at 0.2 dB/div from 40 MHz to 40 GHz at 4 GHz/div .  The following figure shows the Group Delay at 0.2 ps/div from 40 MHz to 40 GHz at 4 GHz/div.   The following figure shows the Insertion Loss at 0.2 dB/div from 40 MHz to 40 GHz at 4 GHz/div.   TYPICAL PERFORMANCE   The following figure shows the Group Delay at 0.2 ps/div from 40 MHz to 40 GHz at 4 GHz/div.   The following figure shows the Return Loss at 0.2 dB/div from 40 MHz to 40 GHz at 4 GHz/div.   STEP RESPONSE   - The following figure shows the step response to a 15 ps rise time input at 10 ps/div.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Picoseond Pulse Labs
MPN 5509
Model 5509
Country/Region of Manufacture United States
