Pixel Blue Backlight Lcd Module Adapter Pcb 84*48 84x48 For Nokia 5110 Arduino

US $2.68

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

a¦aЂ“a°a?a»a?a§a 1/2 aЂ~a©a?aµ 6 84*48 84x48 Pixel Blue Backlight LCD Module Adapter PCB For Nokia 5110 Arduino Description: 100% brand new and high quality 84 X 48 dot matrix LCD, can show 4 lines of characters Use serial interface communicate with the master processor, the number of interface signal line reduced greatly, only 8 signal lines including power and GND. Support different types of MCU, such as the SPI,MCS51 serial mode 0 of AVR . Transfer rate up to 4Mbps,can full speed write display data without waiting time. Can use the conductive glue to connect the module with the printed board, without connecting cable . The metal hooks on the module can fix the module on the printed board, which is very easy to install and replace. LCD controller/driver chip has been bound to LCD chip, the volume of LCD is small Low power supply, the working current in normal situation is lower than 200?A,and has power-down mode. Power supply voltage:2.7V-3.3V,5V is OK, but part of the screen becomes black when tested Data interface level:2.7-5V Backlight power supply voltage: highest 3.3V Module size:43.6mm x 43.1mm(width X height) Installation diameter:2mm Backlight: Blue Positioning holes corners , while providing two rows wiring ports, arranged as follows: 1.RST--------- reset 2.CE------------chip selection 3.DC-----------data/commands choice 4.DIN-----------serial data line 5.CLK------------serial Clock Speed 6.3.3V------------VCC 7.LIGHT--------- backlight control terminal 8.GND-----------power negative Note: 1. "LIGHT" linked with GND, the backlight to be lit. 2. Need you to compress the screen and PCB tighter, might got loose after the delivery. 3 Use a 3.3V controller, otherwise the display could be quite vague. Document for Download :
