Pixhawk Px4 Autopilot Pix 2.4.6 32bit Arm Flight Controller For Rc Multicopter E

US $94.00

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Pixhawk PX4 Autopilot PIX 2.4.6 32 Bit ARM Flight Controller For RC Multicopter Description: - Improvement on board integrated PX4FMU + PX4IO - add the PWM to the PPM module based on the original version of the 3DR - V2.4.6 PCB board - Redeveloped and optimized circuit without changing components - Could use Official MissionPlanner, ECLIPSE firmware upgrade Features: - 168 MHz / 252 MIPS Cortex-M4F - 14 PWM / Servo outputs (8 with failsafe and manual override, 6 auxiliary, high-power compatible) - Abundant connectivity options for additional peripherals (UART, I2C, CAN) - Integrated backup system for in-flight recovery and manual override with dedicated processor and stand-alone power supply (fixed-wing use) - Backup system integrates mixing, providing consistent autopilot and manual override mixing modes (fixed wing use) - Redundant power supply inputs and automatic failover - External safety switch - Multicolor LED main visual indicator - High-power, multi-tone piezo audio indicator - microSD card for high-rate logging over extended periods of time Specifications: Processor - 32bit STM32F427 Cortex M4 core with FPU - 168 MHz - 256 KB RAM - 2 MB Flash - 32 bit STM32F103 failsafe co-processor Sensors - ST Micro L3GD20H 16 bit gyroscope - ST Micro LSM303D 14 bit accelerometer / magnetometer - MEAS MS5611 barometer Interfaces - 5x UART (serial ports), one high-power capable, 2x with HW flow control - 2x CAN (one with internal 3.3V transceiver, one on expansion connector) - Spektrum DSM / DSM2 / DSM-X® Satellite compatible input - Futaba S.BUS® compatible input and output - PPM sum signal input - RSSI (PWM or voltage) input - I2C - SPI - 3.3 and 6.6V ADC inputs - Internal microUSB port and external microUSB port extension Power System and Protection - Ideal diode controller with automatic failover - Servo rail high-power (max. 10V) and high-current (10A+) ready - All peripheral outputs over-current protected, all inputs ESD protected Package Includes: - 1 x The flight controller and shell - 1 x 6S Power-supply module (Power module 3DR can be used on the ground station.) - 1 x Unlock switch - 3 x lagging for mode - 1 x Buzzer - 1 x distributing plate - 2 x 6p to 6p Silicone wire (for power module) - 1 x 4p to4p Silicone wire (for I2C) - 1 x TF 4G card - 1 x TF card reader - 1 x 3M tape - 1 x DuBang wire Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail(( no tracking number for items under $50), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
