PLANS--QCTP-275-S QUICK CHANGE TURRET TOOL POST fits ATLAS, SOUTH BEND, LATHE, US $390 – Picture 0
PLANS--QCTP-275-S QUICK CHANGE TURRET TOOL POST fits ATLAS, SOUTH BEND, LATHE, US $390 – Picture 0

Plans--qctp-275-s Quick Change Turret Tool Post Fits Atlas, South Bend, Lathe

US $390

  • Buffalo, Minnesota, United States
  • May 24th
Open on mobile:
QR code
BUILD YOUR OWN PLANS--QUICK CHANGE TURRET TOOL POST fits ATLAS, SOUTH BEND, LOGAN LATHES and all LATHES TO 16" SWING 2-3/4" square turret block holds (4) tool holders (measures 4" square with tool holders mounted) (Tool slot size is 1/2"). Tool holders are interchangeable with Aloris and Dorian.  Tool holders are quickly changed from the top using a t-handle hex wrench. 12 position positive indexing with detents every 30 degrees Plan also includes optional 24 position indexing with detents every 15 degrees Robust construction Customizable to fit any lathe up to 16" (.813" minimum vertical distance required from the centerline of spindle to the top of cross slide or compound) Repeatable Rigid Smooth and positive operation. The turret block is raised up and off the detents while turning the handle and locks down solidly. There are no springs to fail. Saves set up time on the lathe. Plan includes fully detailed drawings for standard slotted tool holders, boring bar tool holder, parting tool holder, and v-block holder. V-block tool holder can be used for milling key ways, flats on shafts etc. Design lends itself to construction methods that are within the reach of the home shop machinist possessing a lathe with milling attachment. Clear fully detailed CAD drawings(16) 8-1/2" X 11" pages (printed double sided) and construction notes (9) 8-1/2' X 11" pages (printed double sided). Build Your Own Plans Only -ACTUAL ITEM IS NOT FOR SALE - Requires Machining.
