Plastic Transistor Checker Meter Resistors Triodes For Automatic Detection

US $17.21

Shenzhen, China
Jul 26th

Open on mobile:
QR code

Plastic Transistor Checker Meter Resistors Triodes For Automatic Detection Feature: 1. Automatic detection of NPN and PNP transistors, Nchannel and Pchannel MOSFETs, diodes (including double diodes), thyristors, triodes, resistors and capacitors. 2. Added boot voltage detection function, one-key operation, can automatically test the component pins and display them on the LCD. 3. Can detect the amplification factor and base of transistors, MOSFET protection diodes, etc. to determine the forward bias voltage of the emitter transistor. 4. The display uses LCD(128 x 64 characters), measuring gate threshold voltage and gate capacitance of MOSFET. 5. Higher test speed, within 2 seconds of valid component test, (except for larger capacitors, the measurement of large capacitance takes a long time, the 1 minute measurement time is normal). 6. Power consumption shutdown mode, less than 20 nA, automatic shutdown to avoid unnecessary waste, save battery energy, and improve battery life. Specification: Conditon: 100% Brand New Item Type: Transistor Tester Material: Plastic Color: As Pictures Shown Battery(Not Included): 9V Cascade Battery Manual: 1. Use for ATmega8, for ATmega168 or for ATmega328 microcontrollers. 2. 2x16 character LCD display results. 3. One-key operation, automatic power off. 4. The shutdown current is 20nA, which supports battery operation. 5. The low-cost version does not require a oscillator and supports automatic power-off. for ATmega168 or for ATmega328 with 1.05k version software uses sleep mode to reduce power consumption when there is no measurement. 6. Automatic detection of PNP and NPN bipolar transistors, N, P-channel MOSFET, JFET, diode, double diode, thyristor thyristor. 7. Automatically detect the pin layout. 8. Measure the current amplification factor of the bipolar transistor and the threshold voltage of the emitter junction. 9. Darlington transistors can be identified by high threshold voltage and high current amplification factor. 10. Detection of protection diodes for bipolar transistors and MOSFETs. 11. Measure the threshold voltage and gate capacitance of the MOSFET. 12. Support the measurement and signal display of two resistances, the upper four digits and unit display. Both ends of the displayed resistance signal are the connected tester probe numbers (1-3). So the potentiometer can also be measured. If the potentiometer is adjusted to one end of it, the tester cannot distinguish the middle and both ends of the pin. 13. The resolution of resistance measurement is 0.1 ohm, and the high measurement value is 50M ohm. 14. A capacitor can be detected and measured. The upper four digits and unit display. The value can be from 25pf (8MHz clock, 50pF@1MHz clock) to 100mF. The resolution can get to 1 pF (@ 8MHz clock). 15. It can be used to measure the equivalent series resistance (ESR) capacitance value of capacitors above 2UF. The resolution is 0.01 ohms and two-digit values are displayed. This function requires at least 16K flash for ATMEGA (for ATmega168 or for ATmega328). 16. Show signs of the correct direction for the two diodes. In addition, the forward pressure drop is displayed. 17. The LED is detected as a diode, and the forward voltage drop is much higher than normal. The double LED is detected as a double diode. 18. Zener diode can be detected if the reverse breakdown voltage is lower than 4.5V. This will appear as two diodes and can just be determined by voltage. The signal of the probe surrounding the diode is the same, in this case, you can identify the true anode of the diode by the threshold voltage near 700mV! 19. Measure the reverse capacitance of a single diode. Bipolar transistors can also be measured if you connect the base and collector or emitter. 20. Only one measurement is needed to find out the connection of the full bridg. 21. Capacitors with values below 25pf are usually not detected, but they can be connected in parallel with a diode or at least 25pf capacitors in parallel. In this case, you must subtract the part of the parallel capacitance value. 22. Resistance below 2100 ohms will measure inductance, if your for ATMEGA has at least 16K flash memory. The range will exceed 20H from 0:01mH, but the accuracy is not good. The measurement results Only show a single component connection. 23. The test time is about two seconds, Only capacitance and inductance measurements will take a long time. 24. The software can set the number of measurements before the power is automatically turned off. 25. Built-in self-checking function and optional 50Hz signal to check the clock frequency accuracy and waiting for calling (for ATmega168 and for ATmega328). 26. Optional equipment calibration port output internal resistance and 0-offset self-check capability measurement (for ATmega168 and for ATmega328). Need a 100nF to 20uF capacitor connected between pin 1 and pin 3 to compensate the offset voltage of the analog comparator. This can reduce the measurement error of capacitors above 40uF. The internal correction voltage reference voltage with the same capacitor was found to adjust the gain of the internal reference measurement ADC. If the test current exceeds the holding current, the thyristor and triac can be detected. However, some semiconductor thyristors and triacs have higher trigger currents than the tester can provide. The available test current is Only about 6mA! Package List: 1 x Transistor Tester Note: All functions are only used for microcontrollers with more program memory such as for ATmega168. We accept PayPal . We ship item to your PayPal verified address. Payment must be received within 3 days from the date of purchase. All the items will be dispatched within one business day by Airmail after the payment is clear. Most times you will receive your order within 10-30 business days after we transfer your package to the delivery company. We cannot guarantee the delivery timeframe if the post office has any unexpected delays due to holiday, weather, customs, or other conditions. Some countries like Russia, Brazil, or some European countries may take up to 50 days or longer for delivery. We appreciate your patience if you haven't received items in 30 days(Russian customers may need more patience by reason of the local delivery system and/or customs). If you are concerned in any way, please feel free to contact us via ebay message instead of leaving negative/neutral feedback or opening a dispute. We will make every effort to fix any problem(resend or refund any missing item). Customs duty is obligation and liability of citizens in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international duties. 2. duties,taxes,and charges are not included in the item price or shipping fee. 3. The duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the duties will be submitted to ebay for solution. 1. Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. 2. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area 3. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We will do our up most to exceed your expectations in customer service, communication and dispatching of your orders.
