Pocket Size 6 Functions & 14 Ranges Multimeter Moulded Rubber Casing Lot Of 2

US $260

default, default, Hong Kong
Mar 10th

Open on mobile:
QR code

POCKET SIZE 6 FUNCTIONS & 14 RANGES MULTIMETER Moulded Rubber Casing Lot of 2 click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge click to Enlarge Description : This 2 pocket size multimeter is a recifier type, permanent-magnet moving coil instrument designed for measurements of DC voltage, AC voltage, DC current, Resistanceand Decibels. The meter is to operate at an ambient temperature from 0°C to 50°C with relative humidity of less than 85%. FEATURES: (5) five Scales: The upper scale "OHMS" is for resistance measurements The second scale "DCV.mA" is for DC voltage measurements and DC current measurements. The third scale "ACV" is for AC voltage measurements. The fourth scale "BATT" is for battery test. The Fifth scale "dB" is for decibels. Battery check function Full measurement ranges protection Moulded rubber casing Integrated test leads Zero adjust control Pocket-size analog meter SPECIFICATIONS: DC voltage : 0~10~50~250~500V Accuracy at FSD : 5 ; 2000O/V DC Current : 0~25~250mA Accuracy at FSD : 5 AC Voltage : 0~50~250~500V Accuracy at FSD : 5 ; 2000O/V Resistance : 0~10kO~1MO Accuracy at FSD : 5; (arc length) central value 5.5 Decibel : +4 ~ +36dB Battery Test : 1.5V (about 100mA) 9V (about 20mA) Safety Standard : IEC-61010-1, CAT II 500V Withstand Voltage : AC3700V for one minute between internal circuit and housing case Type of Fuse : 500mA / 250V, Fast action, ?5x20mm Overload Protection : Protected by fuse and diode against accidental overload. Operating Environment : Temperature : 0~40°C Relative humidity : <80% Storage Environment : Temperature : 0~50°C Relative humidity : <85% Size : 119 x 85 x 28mm Weight : about 161g SET COMPRISE: 2 x Analog Multimeter 2 x English Instruction Manual Blister Packaging Shipping : Payment : inkfrog terapeak i000000

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	Pocket size Multimeter
Safety Standard	IEC-601010-1, cat II 500V
Five scales	OHMS, DCV.mA,ACV,dB
Type of Fuse	500mA/250V, Fast action, ?5x20mm
DC Voltage	0~10~50~250~500V
Overload Protection	Protected by fuse and diode against accidental ove
DC Current	0~25~250mA
Operating Environment Temp.	0~40°C
AC Voltage	0~50~250~500V
Operating Environment RH	<80%
Resistance	0~10k?~1M?
