Pololu Tic 36v4 Usb Multi-interface Stepper Motor Controller (soldered)

US $51.95

Swanton, Vermont, United States
Aug 16th

Open on mobile:
QR code

Description Pololu Tic 36v4 USB Multi-Interface Stepper Motor Controller Features a soldered, discrete MOSFET stepper motor Supports six control interfaces Connects to a computer through USB The Pololu Tic 36v4 USB Multi-Interface Stepper Motor Controller (Soldered) makes basic control of a stepper motor easy, with quick configuration over USB using our free software. The controller supports six control interfaces: USB, TTL serial, I²C, analog voltage (potentiometer), quadrature encoder, and hobby radio control (RC). This version incorporates a discrete MOSFET stepper motor driver, and it ships with soldered header pins and terminal blocks. It can operate from 8 to 50 V and can deliver up to approximately 4 A per phase without a heat sink or forced air flow (or 6 A max with sufficient additional cooling). The Tic family of stepper motor controllers makes it easy to add basic control of a bipolar stepper motor to a variety of projects. These versatile, general-purpose modules support six different control interfaces: USB for direct connection to a computer, TTL serial and I²C for use with a microcontroller, RC hobby servo pulses for use in an RC system, analog voltages for use with a potentiometer or analog joystick, and quadrature encoder for use with a rotary encoder dial. Specifications Weight: 9.6 g Motor driver: discrete MOSFETs Control interface: USB; non-inverted TTL serial; I²C; RC servo pulses; analog voltage; quadrature encoder Minimum operating voltage: 8 V Maximum operating voltage: 50 V Continuous current per phase: 4 A Maximum current per phase: 6 A Maximum step rate: 50000 PPS Microstep resolutions: Full, 1/2, 1/4, 1/8, 1/16, 1/32, 1/64, 1/128, and 1/256 Reverse voltage protection: Yes Connectors soldered: Yes What's Included 1 x Pololu Tic 36v4 USB Multi-Interface Stepper Motor Controller (Soldered) Dimensions Size 1.50 x 1.05 x 0.47 " Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Pololu
Type	Pololu
MPN	3140
UPC	Does not apply
