Polypropylene Safety Capacitor X2 Cap 0.01uf 103k 300vac Ckx P:7.5mm 30pcs/lot

US $8.00

???, default, Taiwan
Jan 29th

Open on mobile:
QR code

Item description Polypropylene Safety Capacitor X2 CAP 0.01uF 103K 300VAC CKX P:7.5mm 30PCS/LOT CKX are non-inductively would with a metallized polypropylene film dielectric/electrode, encapsulated in flame retardant (UL94, V-0) Plastic case and epoxy resin end seal. ? ? 2000 ? X 2 ? ? ? ? X1 ? ? ICE 384-14, 2nd EDITION 1993 W 18.0 26.5 31.5 37.0 51.0 P 15.0 22.5 27.5 32.5 47.5 d 0.6&0.8 0.8 0.8 0.8 0.8 APPLICATIONS ?lead for use in line bypass, antenna coupling, across-the-line and spark killer circuits. ?Available for EMI filter. ?Switching power supply applications. ?Business machines appliances, such as: adding machines, computer displays and monitors... ?Household appliances, such as: mixers, fans, coffee grinders, DVD player, audio and TV circuits... ?Thyristor and triac appliances, such as: dimmers... FEATURES ?Provides interference suppression, all safety approval. ?Overvoltage stress withstanding. ?Self-healing properties. ?Active and passive flame retardent. SPECIFICATIONS ?Climate Category : In accordance with DIN40040 GMF ....a) G=Minimum Limit Temperature -40°C ....b) M=Maximum Limit Temperature +100c ....c) F=Humidity Category Average relative humidity ?75%, 95% ....for 30 days per year, continuously: 85% for the remaining ... days, occasionally. ?Rated Voltage : 250V / 300V.AC, 50~60Hz ?Capacitance Range : 0.0047~6.8?F ?Capacitance Tolerance : ±5% (J ) , ±10% (K ) , ±20% (M ) ?Withstand Voltage : ....a) Between Terminals ... 1200V.AC, 60Hz or 2200V.DC Is. ....b) Between Terminals and Case ... 2200V.AC, 60Hz, 60s. ?Dissipation Factor : ....a)?0.1% at 1 KHz and 20°C ....b)?0.3% at 10 KHz and 20°C ?Insulation Resistance : ....a) Between Terminals ...3x104M? for C?0.33?F; ....... ?1x104M?.?F for C>0.33?F ....b) Between Terminals and Case ... 3x104M? Measured at ....... 100 ±15V.DC, 60s 20°C ?CKX X1 AND X2 CASE SIZE OF STANDARD PRODUCTS Capacitance Rated-Voltage Dimensions in mm ?F VAC W H T P d 0.0047 300 18 10 5 15 0.6 0.0056 300 18 10 5 15 0.6 0.0068 300 18 10 5 15 0.6 0.0082 300 18 10 5 15 0.6 0.010 300 18 10 5 15 0.6 0.012 300 18 10 5 15 0.6 0.015 300 18 10 5 15 0.6 0.018 300 18 10 5 15 0.6 0.022 300 17 10 5.5 15 0.6 0.027 300 18 11 5 15 0.6 0.033 300 18 10 5 15 0.8 0.047 300 18 10 5 15 0.8 0.056 300 18 10 5 15 0.8 0.068 300 17 10 5.5 15 0.8 0.082 300 17 11 5.5 15 0.8 0.10 300 17 11 5.5 15 0.8 0.12 300 18 12 6 15 0.8 0.15 300 18 13.5 6 15 0.8 0.22 300 17 15.5 7.5 15 0.8 0.22 300 25 14.5 6 22.5 0.8 0.27 300 26.5 16.5 7 22.5 0.8 0.33 300 17 16.5 9.5 15 0.8 0.33 300 26.5 16.5 7 22.5 0.8 0.39 300 26.5 17 8.5 22.5 0.8 0.47 300 17 19 11 15 0.8 0.47 300 26.5 17 8.5 22.5 0.8 0.56 300 31.5 20 11 27.5 0.8 0.60 300 31.5 20 11 27.5 0.8 0.68 300 26.5 19 10 22.5 0.8 0.68 300 31.5 20 11 27.5 0.8 0.82 300 26.5 21 11.5 27.5 0.8 1.0 300 31.5 21 11.5 27.5 0.8 1.0 300 30 24 13.5 32.5 0.8 1.2 300 30 24 13.5 32.5 0.8 1.5 300 37 26.5 16 32.5 0.8 1.8 300 37 26.5 16 32.5 0.8 2.2 300 37 26.5 16 32.5 0.8 2.7 300 37 28.5 18 32.5 0.8 3.3 300 37 34 22 32.5 0.8 3.3 300 51 27.5 17.5 47.5 0.8 3.9 300 51 27.5 17.5 47.5 0.8 4.7 300 51 30.5 20 47.5 0.8 6.8 300 51 35 24 47.5 0.8 Payment Information ? We accept Paypal payment only , you can use credit card through PayPal. ?If you bid or buy more than one item, please pay all of them in one single PayPal transaction shipping Information ?Shipping address:Please make sure to provide us with correct, precise, and detailed shipping Address. ?Send Time:Items will be shipped by air mail within 1-2 days after payment received. ?Delivery Time:USA, Canada, Australia, West and North Europe 10-20 Business Days, other countrys may take 15-25 Business Days. ?In addition, If you don't receive items over 30 business days, please contact us. Return policy ?unquestionable, If you are not satisfied with our products, we will resend or refund your full money. Contact us ?Any inquiry, please feel free to contact us with EBAY message. Your questions will be replied within 24 hours.
