Positive And Negative Power Supply Board Module -12v 3a Lm2596

US $600

Shanghai, China
Jun 22nd

Open on mobile:
QR code

Positive and Negative Power Supply Board Module -12V 3A LM2596 Description Features: Can be negative power supplied for dual power op amp and other applications require a negative power supply Onboard Chip LED power indicator With thermal shutdown and overload protection With a toggle switch that controls the power supply board is closed off With power adapter input interface (DC Block Specification 5.5 * 2.1mm) Size:60*30mm Max Output Current:3A Instructions: Positive voltage VIN port is the power adapter's terminals,if the power adapter is 12V,then the VIN terminal voltage is 12V,so you can get the VIN and VOUT-end negative voltage 12V. When you do not use the power adapter as the input,you also can direclty input the voltage from VIN termimal to enable the chip producing a negative voltage. LM2596 chip can be controled on and off by the CTR pord,when CTR input high level,the chip will start, and the VOUT-end will get-12V;when CTR vacant input low,the chip will close. If not control,CTR can be directly connected to VIN and get hight level together,you can use jumper cap shorted VIN and CTR,do not exceed 25V CTR high level. VIN input voltage range is 5-35V. Package List: 1pcs Positive and Negative Power Supply Board Module -12V 3A LM2596 Payment We accept Paypal as the payment method. Shipping policy The default shipping is by China Post air mail/Hongkong air mail. We provide combined shipping to USA by e-Packet service. When you place order for multi items,please contact us. We will only charge you 1.8USD shipping cost for the whole order. Item will be shipped within 1-2 working days after full payment is received. The delivery to most of the countries will take 2-4 weeks, if there's no problem when pass through the customs. We only accept your eBay address. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. The extra fee occured when the product pass through the customs should be paid by buyer Return policy If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money. If you don't satisfy with our product,please help to post our product back to us.You should pay the post back postage.After we receive our product,we promise to payback 100% of your money. About us We sell Electronic Components including Capacitors, Resistors, LEDs, Transistors, IC's, Bridge Rectifiers and other hard to find parts. We can also provide customized design and manufacture services. Contact us If you have any questions, please feel free to email us , and we will reply you ASAP.
