Potable Digital Multimeter Lcd 3 1/2 Digit Volt Amp Ohm Test + Probe 1999 Display

US $15.31

Shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Test Equipment GPS Antenna GSM 3G Antenna Other Antenna RF Cable Assembly RF Connector RF Adapter Potable Digital Multimeter LCD 3 1/2 Digit Volt AMP OHM Test + Probe 1999 Display Product description : click to browse more test equipment~ NEW Arrival! 100% BRAND NEW & HIGH QUALITY! Feature: -- Smaller and easy to carry, cost efficient, comfortable hand feeling --3 1/2 Digital LCD display, maximum display 1999 --Low voltage indication --Overload Protection (0.2A/250V fuse, 10A no fuse) --With test probe leads, wide range of application --Diode and transistor test Technical Characteristic 1. DC Voltage: Measuring Range Resolution Accuracy 200mV 100mV ±(0.5%+2) 2V 1mV ±(0.5%+2) 20V 10mV ±(0.5%+2) 200V 100mV ±(0.5%+2) 600V 1V ±(0.8%+2) Input Resistance: ≥1MΩ Maximum Input Voltage: 600V DC or AC effective value 2. DC Current: Measuring Range Resolution Accuracy 20μA 10nA ±(1%+2) 200μA 100nA ±(1%+2) 2mA 1μA ±(1%+2) 20mA 10μA ±(1%+2) 200mA 100μA ±(1.2%+2) 10A 10mA ±(2%+2) Overload Protection: 0.2A/250V fuse, 10A no fuse 3. AC Current: Measuring Range Resolution Accuracy 200V 100mV ±(1.2%+10) 600V 1V ±(1.2%+10) Frequency Response: 45~400Hz Maximum Input Voltage: 600V AC effective value Display: Sinusoidal RMS, average response 4. Resistance: Measuring Range Resolution Accuracy 200Ω 0.1Ω ±(1%+5) 2KΩ 1Ω ±(1%+5) 20KΩ 10Ω ±(1%+5) 200KΩ 100Ω ±(1%+5) 2MΩ 1KΩ ±(1%+5) Maximum Open Circuit Voltage: 2.8V Overload Protection: 250V DC or AC effective value, less than 10sec. 5. Triode hFE Parameter Test: Measuring Range Display Value Test Condition NPN, PNP 0~1000 Base current approx.10μA Vcc 3V 6. Diode and Continuity Test: Diode testing voltage current: Approx. 2.4V, 1.5mA, display approximation of diode positive voltage drop, buzzing when the resistance of both test points less than 7Ω Specification: Product Name: Digital Mulitmeter Product Model: DT830LN Display: 3 1/2 digits LCD, Maximum display 1999 Operating Condition: Temp 0~40℃,Relative Humidity: ≤75%RH Storage Environment: -15~50℃ Battery: 9V Dimension: 105*60*27mm (L * W * H) Weight: 150g Package Content: 1pcs Digital Multimeter+test probe (not include battery) Recommend Products Digital LCD Watt Meter Power Volt Amp Meter RC Battery Analyzer 60V 100A DC NEW New 5pcs Silicone High Voltage Banana to Banana Plugs Test Leads Cable 5 Colors 1Set Dual Injection 4mm Banana to Banana Male Plug Test Probe Leads Cable 1M 15A 30pcs 5 Colors SMD IC Logic Analyzer Mini Grabber Test Clip Hook Probe Jumper 20pcs Insulated Shroud Stackable 4mm Banana Plugs Connectors Male Jack Red Black Dual Display Green Red LED Digital Current Voltage Panel Meter DC0-100V 10A 0.28 15V DC Analog Panel Meter Voltage Volt Meter Voltmeter White 0-15V 65*56mm 85C1 DT-9205M Digital Multimeter Voltmeter Ammeter Ohmmeter Capacitance Tester LCD Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	TOOL077-DT-830LN
Dimension	1056027mm (L * W * H)
Product Name	Digital Multimeter
Display	3 1/2 digits LCD, Maximum display 1999
Product Model	DT830LN
Storage Environment	-15~50°C
