Power Amplifier Kit 56w Rms Audio Hifi Amp Low Thd K333-:

US $110

Valley Stream, New York, United States
Jan 29th

Open on mobile:
QR code

56W Power Amplifier Kit Power Amplifier KIT using LM3875, 56W rms Audio HiFi Amplifier, Low THD, K333 Lot Size: 1 units See other audio amplifiers LM3875-TF "GainClone" on best quality Blue Gold-plated epoxy PCB, with 4x 2200uF 50V Japanese Low-ESR capacitors 56W rms, into 8Ohm, 1 Channel 0.01% total harmonic distortion, >92db SN ratio. TO220 insulated case Uses the "Overture" LM3875 Power Amplifier IC. Requires soldering. Build a professional, high-end audio amplifier that is fully short-circuit protected, thermally protected, and performs on par with audiophile HiFi sound equipment. The kit enables the building of either an inverting or non-inverting amp. All parts are provided for BOTH versions. You choose which parts you populate to obtain the amplifier you want. High quality FR4 double-sided, plated-thru and gold plated holes, with blue conformal coating, solder mask and silkscreen. The Printed Circuit Board implements a ground plane, and "star" grounding. 2 individual amplifiers can be paralleled for double the power into 4 Ohm loads National Semiconductor document on BPA200 Bridge-Parallel 200W+ Amp http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=180660529546 Kit contains PCB, all parts, and 5-page instruction sheet, for ONE CHANNEL of the amplifier. Heat sink and power supply not included. Requires a dual 30V to 43V DC power supply. PCB is double-sided ground-plane FR4 epoxy, gold plated over nickel. Film capacitors are high quality polymer film, all resistors are low-noise metal film. 2 Surface-mount 1uF 100V MLCC bypass capacitors provided. (value $4 each) 4 High quality 2200uF Low ESR Japanese SXE series capacitors made by Nippon ChemiCon, for a total of 4400uF pulse energy power on each rail for fast bass transients. 2 Surface-mount 2.2uF 50V MLCC bypass capacitors provided. (value $4 each). Below an example of completed amplifier with added heartsink - HEAT SINK NOT INCLUDED IN THIS EBAY LISTING Heat removal solutions are dependent on enclosure choices: (large, small, ventilated, slim ) and will dictate choice of cooling- such as a small heatsink with a low speed fan forcing air over it, to achieve a slim case configuration, for example. I can only ship to buyer's EBAY profile shipping address IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. International : If you want seller to be responsible for package in transit , you must choose Registered mail - adds $13 to S&H - contact seller for invoice. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf
