Power Analyzer Av Power Pa4400a

US $2,750.00

Laguna Niguel, California, United States
Jan 29th

Open on mobile:
QR code

Power Analyzer AV power PA4400A Power Analyzer AV power PA4400A An easy to use and powerful 3 phase 4 channel Power Analyzer from Powertek The PA4400A series offers single phase, two wattmeter and three phase power analysis, with full power meter and watt meter capability. Three phase power analyzers / watt meters are a necessity when several ac power measurements need to be recorded during testing - from one set of input connections. Three phase watt meters are important when accurate watts measurement is necessary for certification and traceability. In addition to power measurement (watts), energy, reactive power (VAr), apparent power (VA), voltage rms, current rms, power factor and harmonics, can all be viewed with ease. All Powertek power meters / wattmeters simply connect between the ac supply and the load, various current transformer and shunt options allow measurement with any level of current amplitude. Typical three phase watt meter applications include appliance testing like generators, electric stoves, heating, air conditioning, pumps, fans, electronic lighting and motor controllers. All our power meters are equipped with safety terminals (4mm/banana) along with optional "breakout" boxes and clamp probes for fast and safe measurement. Click here for PA4400A Datasheet pdf ? 500kHz Bandwidth ? 1440Vpk + 125Apk direct measurements (DC coupled) ? 4 Fully isolated and independently ranged input channels ? Up to 10 readings per second ? Torque/Speed input (option) ? PWM Filter for motor drives ? Flexible wiring configurations 3Ø4w+Torque, 3Ø4w+1Ø, 3Ø3w+3Ø3w etc. ? Harmonics to the 80th ? IEEE-488 and RS232 interfaces ? Integrator function with WHRS, AHRS and elapsed time ? 10 setup memories for storing individual configurations ? Efficiency & energy measurements ? 10 Chart recorder outputs (option) ? Inrush current measurement ? Printout graphics or lists Multiple Parameter Display View results on all four channels plus neutral and Sum. Choose between individual channels or all results on one page. Scaling factors may be applied to give correct readouts when using VT and CT. One key access to most display functions. Waveforms + Chart Recorder Functions View volts, amps and watts waveforms for each channel. Use datacapture to store and analyse transient events. A chart recorder function graphs a selected parameter over time. Harmonic Analysis Harmonic analyser allows user to view harmonic lists or bar graphs for all four channels. Amps and volts THD is calculated from the harmonic series Measurement Function PA4400A Measurement Bandwidth Range DC, 0.2Hz to 500kHz Volts Display Resolution 4 3/4 digit Measurement Range 700mVrms to 1000Vrms (1440Vpk) (200mVrms with display blanking off) Vpeak Ranges 1440, 720, 220, 110, 33.0, 16.0, 5.0, 2.5 Max input volts 1440Vpk Overload 3000Vrms for 1 second Accuracy 0.1% Reading +0.1% Range +10mV DC 0.5% Reading +0.5% Range +10mV Common mode 90dB Input impedance 1Mohm 12pF Current Display Resolution 4 3/4 digit Measurement Range 0.01Arms to 20Arms (125Apk) Ext Shunt 1mVpk to 4Vpk Apeak Ranges 125, 62.5, 22.0, 11.0, 3.50, 1.80, 0.6, 0.3 Max input amps 20Arms continuous 125Apk Accuracy 0.1% Reading +0.1% range +2mA DC 0.5% Reading +0.5% Range +10mA Common mode 90dB Input impedance 0.02Ohm Power Accuracy 0.1% Reading +0.1% range +2mW VA Accuracy 0.1% Reading +0.1% range +2mVA VAR Accuracy 0.1% Reading +0.1% range +2mVAR General Specifications Interfaces Standard Printer (Centronics) Optional IEEE-488, RS232, Chart Recorder x 10 Environment Operating Temperature 0ºC to +50ºC Storage Temperature -40ºC to +60ºC Humidity 10% to 90% RH non-condensing Dielectric Strength Inputs to case 4kV AC 50/60Hz for 1 minute AC line input to case 2kV AC 50/60Hz for 1 minute Power AC line input voltage 90V to 264V AC line input frequency 45Hz to 450Hz AC line input fuse 20mm 1AT Power consumption 25W/40VA Mechanical Weight 9.0kg Dimensions (W x H x D) 430mm x 144mm x 420mm Options and description PA4400A-3 Three Phase Power Analyser - 3 Channel PA4400A-4 Three Phase Power Analyser - 4 Channel PA4400A-3-B With Blank Front Panel PA4400A-4-B With Blank Front Panel Option 68 Interface Board (use with Option 68A, 68B, 68C) Option 68A RS232 Option 68B IEEE-488 Option 68C Chart Recorder O/Ps * 10 Option 03 500A PA Series Current Transducer 100:1 Option 04 1000A PA Series Current Transducer 1000:1 Option 22 PA4400A Rack Mounting Kit Option 25 HV 40kVpk 2000:1 Probe Option 29 PA4400A-3 Test Lead Set Option 29A PA4400A-4 Test Lead Set Option 43 PA4400A-3 UKAS Certificate Option 44 3000A Clamp Current Transformer Option 46 PA Series 1mA to 500mA non inductive shunt Option 49 1250A/125A:1A (1500A max) 0.2% CT Option 50 PA4400A-4 Torque/RPM Input Option 51 Hall Effect sensor 50A Current CT Option 52 Hall Effect sensor 100A Current CT Option 53 Hall Effect sensor 200A Current CT Option 54 Hall Effect sensor 300A Current CT Option 55 Hall Effect sensor 500A Current CT Option 56 Hall Effect sensor 1000A Current CT Option 57 Wiring/Housing for LEM's (PSU not inc.) Option 58A 1A PSU for Hall Effect Transducers (cased) Option 63 AVLab 44 for PC This unit has been tested and known to be in good basic operational condition and will be refunded if DOA, however, there is no specific warranty offered. This is used equipment and sold as is. Good luck on Your Bid !! .
