Power Supply, Open Frame, 5v@8a, Condor Gpc40-5, 40watt Ac Input

US $1500

  • Meriden, Connecticut, United States
  • Oct 22nd
Open on mobile:
QR code
Ac Input:  85-264 Vac, 47-63 Hz single phase. Input Current:  Maximum input current at 120 Vac, 60 Hz with full rated output load: 1.3 A Hold-Up Time:  20 ms minimum from loss of ac input at full load, nominal line (115 Vac). Output Power:  40 W continuous, 50 W peak. Peak ratings are for 60 s maximum duration, 10% duty cycle. During peak load condition, output regulation may exceed total regulation limits. Overload Protection:  Fully protected against short circuit and output overload. Short circuit protection is cycling type power limit on outputs 1 & 2; foldback type on output 3. Recovery after fault is automatic. See output ratings chart for additional notes or conditions. Overvoltage Protection:  Main outputs: 124% ± 12%. Efficiency:  70% at full rated load, nominal input voltage, depending on model and load distribution. Turn-on Time:  Less than 1 second at 120 Vac, 25°C (inversely proportional to input voltage and thermistor temperature). Note that output trimming is ±5% of 5V (5.25 to 4.75V) Input Protection:  Internal ac fuse provided. Designed to blow only if a catastrophic failure occurs in the unit. Inrush Current:  Inrush is limited by internal thermistors. Inrush at 240 Vac under cold start conditions will not exceed 34 A. Temperature Coefficient:  0.03%/°C typical on all outputs. Environmental Designed for 0 to 50°C operation at full rated output power; derate output current and total output power by 2.5% per °C above 50°C.
