Power Werx Ss-30a Power Supply - Two Way Radio

US $80.00

Pensacola, Florida, United States
Jan 29th

Open on mobile:
QR code

Brand new Power Werx SS-30A switching power supply that switches from 110v to 220v with a simple switch on the back of the power supply. The power plugs in to your wall outlet and flip the power on and off switch to turn on and off it lights up as well. It's in excellent condition as I kept it in. Very easy to hook the wires of any kind to your application such as commerical radio, ham radio or home use that uses 220v home current. The power supply has four power connections on front and two on the back side. Description The Powerwerx Switching Power Supply Model SS-30DV is designed to supply 25 Amps continuous and 30 Amps surge (up to 5 minutes) at 14.1 VDC. Loads can be connected to either the rear binding posts or the front Powerpole connectors. Any output may provide up to 30 Amps individually, and the total output is limited at 30 Amps. Features Front Connection: 2 sets of Powerpole connectors Rear Connection: 1/4 inch binding posts that also accept banana plugs, 1/4 inch ring terminals or compression connections Illuminated Power Switch Specifications Electrical specifications: Input Range: 100-120 VAC or 200-240 VAC, 50/60Hz (Switchable) New! Output Voltage: 14.1 VDC fixed Output Amperage: 25 continuous, 30 surge Internal Protection: Thermal, over current Internal Input Fuse: 6.3 Amps at 115 VAC Ripple Peak-to-Peak Max. <100mVpp Noise Peak-to-Peak Max. <100mVpp Operating temperature rating: 0 – 50 °C Storage temperature: -20 – 85 °C Physical dimensions and materials: Weight: 3.0 lbs. (48 oz.) Overall Dimensions: 6.1 x 5 x 2.5 in (154mm long, 127mm wide, 63mm tall) Fan: Quiet internal cooling fan Machined metal case front bezel Certifications Meets FCC CFR Title 47 Part 15 Subpart B: Class B, CISPR: 2005 ANSI C63.4: 2003 Meets CE/LVD (Low-Voltage Directive 2006/95/EC) standard Meets EMC: EN 55022:206+A1: 2007, 2010, EN 61000-3-2:2006 Powerpole Configuration The Powerpole connectors mounted on the front panel conform to the RACES/ARES standard orientation. Input Voltage Selection The power supply is set up for 230V AC input as shipped from the factory. For 115V AC applications, set the recessed 115/230 input select switch located on the rear of the power supply into the proper position. Positions are identified on the switch. Use a small screwdriver to slide the switch into position. No adjustment is necessary for either 50 or 60 Hz input. Applications Land mobile radio base stations Communications systems Security systems Automotive & marine systems OEM applications Test equipment Electronic displays 12 Volt lighting systems GPS receivers DC computers Package Contents Power Supply AC Power Cord, 4 ft. Installation Instructions Unplug the power supply from the mains supply outlet. Select the correct input voltage (See Input Voltage Selection). Connect the power cable’s positive (red) wire to the positive terminal and connect the negative (black) wire to the negative terminal on the back of the power supply or use the Powerpole connectors mounted on the front panel. Plug the power cable into the power socket on the back of the radio. Plug the power supply into the mains supply outlet. Turning the power supply on Turn the power supply on by pressing the power switch to the 'ON' Position. Turning the power supply off Before you turn the power supply off, turn the radio off as described in the user documentation for the radio. Then turn the power supply off by pressing the power switch to the 'OFF' Position. Cooling The SS-30DV power supply is cooled by convection and forced air cooling (normal airflow around the power supply in combination with a temperature controlled fan to improve cooling at higher levels of use). The fan is activated by a sensor when the temperature rises above 70°C. Read more: http://www.powerwerx.com/power-supplies/powerwerx-30-amp-desktop-switching-power-supply-powerpoles.html#ixzz3K9HKvYOg

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Brand new out of the box. It comes with the original box as shown in the pictures and the user manual.”
