Pressure Transmitter Pressure Transducer 0-10bar 9-32vdc G1/4 4-20ma Output 0.5%

US $1500

Shanghai, China
Jun 3rd

Open on mobile:
QR code

OEM Service; Customized Service; Best Price and High Quality,18 Months Quality Guarantee,reject the poor quality; Our Company Was Founded in 2004. CE Certificate; ISO9001; Explosion-proof Certificate for Pressure and Level Sensor; CMC for Load Cell Sensor; CMC for Pressure and Pull Pressure Sensor. Parameters: Capacity Range:0-10bar(gauge pressure); Comprehensive Precision:0.5%FS; Output Signal:4-20mA; Overload Capacity:2-4 times Using Temperature Range:-40 to 110C; Power Supply:9-32VDC; Pressure Medium:Non-corrosive liquid or air; Temperature Effect on Zero:Typical:0.02%FS/C;Maximal:0.05%FS/C; Temperature Drift on Sensitivity:Typical:0.02%FS/C;Maximal:0.05%FS/C; Shock Resistance:1000g; Housing Material:Stainless Steel; Pressure Connection:DIN type; Blast Proof Class:ExiaIICT6; Long-term Stability:less than 0.1%FS/year; Defend Grade:IP68; Pressure Connection:G1/4; Cable Connection:Red(IN+); Black(IN-) Applications: Air compressor and pump; Liquid pressure and air pressure system; Energy resources and water treatment system; Refrigerating equipment; Automatic detection system; Locomotive brake; Environmental protection field; Agriculture application and mechanical automation. Shipping: 1, Will ship out the goods within 1 business day upon receipt of the payment; 2, e-Packet with tracking number(will take 7-12 working days) to United States; 3, China Post Air Mail with tracking number(will take 20-30 working days) to all over the world; (Note: sometimes the delay will be taken place on account of the weekends,the bad weather,holiday and other reason.) 4, The items can be shipped out through fast way DHL,FedEx,UPS etc if pay the extra freight,the cost of post air mail will be deducted from the fast mode of transportation,contact with us if have any question. Have stocks for following parameters: 0-10bar;0-16bar;0-25bar;0-40bar;0-59bar with G1/4 or NPT1/4 connection,the items can be customized according to the technical parameters. Please view in our store: http://stores.ebay.com/Ahead-Instruments-and-Electronics/Pressure-Transmitter-/_i.html?_fsub=5475108013&_sid=1086435763&_trksid=p4634.c0.m322 Suitable display meter for the pressure transmitter: http://www.ebay.com/itm/Pressure-Transducer-Display-Meter-Sensor-Display-Meter-Output-4-20mA-0-3-F-S-/182090423573?hash=item2a656f5d15
