Process Loop Calibrator Output 0-20ma Analog Transducer -22ma Loop Power 24v

US $240.00

  • Shenzhen, China
  • Jan 29th
VC05 Features: 1. Basic accuracy 0.05%, display 5 digits. 2. Measures DCV and DCA. 3. Output DCA and analogue transducer. 4. Loop power 24V. Specifications: Input Range Input range Resolution Accuracy Explanation Voltage 28V -0.200 ~28.000V 1mV ±0.02% reading ±2mV Input resistance 2M? Current 20mA -1.000~22.000mA 0.001mA ±0.02% reading ±4uA Input resistance 20M? Loopcurrent 20mA 0.000~22.000mA 0.001mA ±0.02% reading ±4uA Supply 24V loop power   Output Range Input range Resolution Accuracy Explanation Current 20mA 0.000~22.000mA 0.001mA ±0.05% Setting value ±4uA 20mA,the max.overload is 1k?(Note1) Analogue transducer -20mA 0.000~-22.000mA 0.001mA ±0.05% Setting value ±4uA 20mA,the max.overload is 1k?(Note2) Looppower 24V ±10% The max.output current is 25mA   Power 9V battery (ANSI/NEDA 1640A or IEC 6LR619 alkaline) or AC power adapter Battery Approx. 20 hours under the condition of 10mA Max.allowable voltage 30V Operation temperture range 0-50°C Operation humidity range
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Model VC05
Country of Manufacture China
MPN VC05
Country/Region of Manufacture China
