Proctor & Schwartz #600 Garnetts Specialized Carding Machines Four Lines Textile

US $2337

Cheraw, South Carolina, United States
Nov 5th

Open on mobile:
QR code

PROCTOR & SCHWARTZ #600 GARNETTS SPECIALIZED CARDING MACHINES Four Lines of Proctor & Schwartz Specialized Carding Machinery #600 Type 20/30, 60” Wide Garnetts. Carding and garnett machinery are very similar. Both process fiber into a uniform form with all the fibers alined. The card’s end product is a round rope product “yarn” that is used to produce thread. The garnett produces a 60” fiber web that is layered to produce a roll for quilting or batt for furniture cushioning. Our garnett machinery is still in a manufacturing layout. Each section has be described for your review: OPENING SECTION: All four garnett lines are connected to primary opening line of picker/blender/hopper machinery. Blended fibers are transferred by an automatic feeding system that transfers fiber into each line’s condensor-feed hopper-shuts feed on a demand basis. The fiber amount given to each line is regulated by electronic eyes places in each line’s feed hopper. FOUR 20/30 60” PROCTAR & SCHWARTZ FIBER GARNETTS Each line has 60” 20/30 Main Cylinders (First opening cylinder with 20” diameter), (Second finishing cylinder with 30” diameter) Two Doffers with 16” diameter 20” Cylinder has 2 workers and 2 strippers 30” Cylinder has 2 workers and 3 strippers 2 fancy rolls 8” diameter 2 Stripper 4” diameter 1 Angle stripper 6” diameter 1 Fiber Return to condensor 1 Main motor 220 Volts 3 phase *These garnett cylinders and rolls are wired to run a single natural fiber or a combination of natural and man-made fibers. Types Used: 1. Cotton pre-cleaned. Est. production per line of 500 lb./hour. 2. Cotton Card or Gin Motes. Est. production per line of 480 lb./hour. 3. 30% poly & 70% cotton pre-cleaned approx. 525 lb./hour per line. 4. 35% poly & 65% cotton first cut linters approx. 550 lb./hour per line. FINISING SECTION PER LINE 2 Comb-bar take offs with transfer shoots 1 60” Wood Slat Crosslapper FIBER TAKE OFF SECTION SUPPORTS TWO GARNETT LINES 2 (90”) Slat Wood Feed Aprons 2 Sets of Compression Rolls 2 Variable Speed (+/- 2 oz. per linear yd.) 4 Trimming Edge Knives 2 Opposing Take Off Rolls End Product: Rolled Fiber for quilting with maximum width of 90” Roll weight variance 18 to 60 oz. FIBER RECLAIM /FILTRATION SYSTEM System was designed to remove small and fine particle fibers produced during the normal producing of four garnetts. This filtration system was approved using pre-cleaned cotton fiber by DHEC & EPA SECTIONS: 1 (60”) main filtration system trunk line connecting all 4 lines with each garnett line’s opening, middle and finishing sections. Reclaimed fiber is returned to its condensor. All fine particle is sent to the rotary-drum air cleaner. 4 Fiber reclaim section is placed over each line’s opening & breaker of 20/30 garnett sections. Reclaimed fiber sent back to each condenser/hopper for recycling. 4 (20/30) filtration section removes fine particles from blending, condenser, hopper, & 20/30 sections and is sent through main 60” filtration trunk line that feeds into the primary/rotary-drum filter. This filter section is divided into 2 cleaning sections:primary rotary screen, secondary rotating drum. The primary filter collects small particle fibers using a rotary screen vacuum that transfer it to a turn-screw bag compactor. The secondary filter removes the fine particles using a rotary drum filter system. **Any questions or to arrange inspections message me please. Pricing is for the entire system: Complete garnett machinery of 4 garnetts including the opening/fiber transfer, garnetts, finishing, take off, filtration sections and spare parts. Four garnetts, including one which needs to have two new main cylinders installed (new main cylinders included) If you are interested in purchasing part of the systems instead of the whole thing message me for pricing options. Have an extensive inventory of parts and accessories available for purchase also including: motors (220) gears sprockets cylinders main cylinders strippers workers garnett parts PURCHASING DETAILS: Priced fob Wallace, SC 29596. First buyer chooses specific sections. Machinery is still placed in producton line. Buyer is responsible for removing all purchased sections. Buyer responsible for any damage incurred to building or unpurchased machinery sections during dismantling process. Proof of insurance required before your personnel will be allowed in the plant. *****NO RETURNS ON THIS LISTING!!!!!!******* *****NO SHIIPPING - BUYER RESPONSIBLE FOR DISMANTLING EQUIPMENT AND REMOVING IT FROM PLANT***** Please pay within 4 days of purchase, or message me upon purchase to let me know when you expect to pay. Thank you! Check out my other items! Be sure to add me to your favorites list! Stores
