Proffessional Compact Cnc Plasma Thc Controller ( Torch Height Control )

US $269.00

Grodkow, Poland
Feb 13th

Open on mobile:
QR code

If you will check delivery via UPS ( cost 28USD ) i will send via DHL Service ( require your phone number ) Estimated delivery time: 1 - 4 business days. if you have VAT EU number i will accept your offer -10% User's guide [ EN ] User's guide [ ESP ] User's guide [ PL ] Oryginal (from the Proma-Elektronika company) Device for professional use ( 100% duty time ) 100% satisfied customers We accept returns if you not satisfied ( full payment return ) User's guide, invoice and warranty include. Ready for use! Very easy to install and configuration The device works with any plasma cutter You don't need a voltage divider or additional components For example this device works with MACH2, MACH3, EMC1 or any program / system that accepts THC UP/DOWN signals. The device is a modern analog - digital controller of height of a plasma torch over a cut material. It is based on analysis of change of voltage generated by a source of plasma. Simplified block diagram: Specification: Supply voltage (V) 7 – 35V DC Input LOW voltage 0-10V DC (from cuter voltage divider 1:50) Input HI voltage 20-300V DC Ability of HV/HF ionization voltage suppressing 30kV Ability of HV/HF ionization frequency suppressing >100kHz Duty cycle (%) 100% Duty cycle of HV / HF suppression (%) 100% Rated max. load 1,25A / 60V DC Relay reliability (minimum amount of cycles) under load of 5V / 10mA : 500*10^6 Degree of protection of enclosure IP IP20 Weight (g) 180g Dimensions (width*length*height) 33*89*65 Mounting DIN 35 rail country of origin : POLAND Example for MACH3 DEMO configuration : This device connect to your system the same as home switch, e-stop etc, the connect diagram is dependent on your system. Before buy you can test your system with switches connected to your system - you simulate the thc up/down signals and make sure that this device will work with your system properly. Example for Plasma-Voltage connection PLASMA CUTTER WITH VOLTAGE DIVIDER 1:50 OUTPUT : PLASMA CUTTER WITHOUT VOLTAGE DIVIDER OUTPUT : Example for connection ( arc ok signals isn't require ) Example for Gecko540 driver connection Clients VIDEO (old version without 1:50 divider input) I can't declare lower value on the shipment doc Shipping from Polish to European Union : Registered mail (tracking). Estimated delivery time 5-10 business days DHL: 1-2 business days Shipping from Polish to Outside European Union : Registered mail (tracking). Estimated delivery time: 12 - 23 business days DHL 2-4 business days Attention: I send in the day of pay or next bussines day (rarely max. 2 days).

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Proma-Elektronika
Country of Manufacture	Poland
Model	Compact THC 150
