?promote & Free?5axis Nema 34 Cnc Stepper Motor 1090oz Spindle & 2 Nema23,425oz

US $395.00

United States
Jan 30th

Open on mobile:
QR code

Great News from Wantaimotor! Ship from USA warehouse, after payment, within 3-5 days for receiving products! No taxes from customs, no damage, better service, only for 5 sets, please don't hesitate! This item includes: 2 PCS Nema 34 stepper motor with 1090oz-in for Single shaft, 3 PCS Nema 23 Stepper Motor with 425oz-in for single shaft, 2 PCS DQ860MA Stepper Driver with 80VDC,7.8A, 256 Microstep, 3 PCS DQ542MA Stepper Driver with 50VDC,4.2A,128 Microstep, 1 PC 350W,36VDC,9.7A Power Supplier, 2 PCS 350W,60VDC,7.3A Power Supplier, 1 PC Breakout Board + 1 Cable. http://www.wantmotor.com 1, Stepper Motor 1, Technical Specifications Part No.: 85BYGH450D-008 Frame Size: NEMA34 Step Angle: 1.8 degree Voltage: 2.13V Current: 5.6A/phase Resistance: 0.38 Ohm/phase Inductance: 4.1 mH/phase Holding torque: 7.7N.m 1090oz-in Rotor inertia: 1700g-cm2 Number of wire leads: 4 Weight: 3 kgs Length: 100mm Note: Nema 34 Stepper Motor with 1090oz-in holding torque on Single shaft, front shaft length is 37mm with 25mm flats length, the diameter for motor shaft is 14mm. RED A+ GREEN A- YELLOW B+ BLUE B- 2, Stepper Motor Driver DQ860MA Introduction The DQ860MA is an economical microstepping driver based on patented technology of Wantai Motor .It is suitable for driving 2-phase 4-phase hybrid stepping motors .By using the advanced bipolar constant-current shopping technique ,it can output more speed and torque from the same motor,compared with traditional drivers ,such as L/R drivers .Its 3-state current control technology allows coil currents to be well controlled and with relatively small current ripple,therefore less motor heating is achieved. Features ?Low cost and good high-speed torque ?14 selectable resolutions ?Supply voltage up to +80VD ?Suitable for-2-phase and 4-phase motors ?Output current up to 7.8A,5.86A rated current, 256 Microstep. ?Dip switch current setting 8different values ?Optically isolated input signals ?Pulse frequency up to 200KHz ?Automatic idle-current reductiOn ?Small size (107*97*48),Weight:0.6KGS 3, Stepper Motor Technical Specifications Part No.: WT57STH115-3004A Single shaft Frame Size: NEMA23 Step Angle: 1.8 degree Voltage: 6.3VDC Current: 3.0 A/phase Resistance: 2.1 Ohm/phase Inductance: 9mH/phase Holding torque: 30Kg-cm 425oz-in Rotor inertia: 810 g-cm2 Detent torque: 0.89 kg-cm Number of wire leads: 4 Weight: 1.8KGS Length: 115mm 4, DQ542MA driver 5, Power Suppy 350W,48VDC,7.3A, 350W,36VDC,9.8A, 6, Breakout Board Description: Built in DB25 male connector. DB25 Output Pin:P1,P2,P3,P4,P5,P6,P7,P8,P9,P14,P16,P17. DB25 Input Pin: P10,P11,P12,P13,P15. DB25 GND Pin: P18-P25. Power supply: +5V DC. Built in C-class Optical-coupler. High quality with Surface-mount Tech. Our products are mainly used in robotization, Spinning Automatization, Printing, Packing, Medica Machine, Make-up Equipment, Communication, Household Appliance, Water Pump, Milling Machine, Engraver Machine, CNC Routers.. etc automatic equipment of various trades. We ship Worldwide! We send by express shipping like EMS, DHL, FEDEX, UPS ,TNT and so on! We product all kinds of motors & driver. And we can manufacture products according to our customer's design. Currently we are looking for qualified stocking distributors with competitive price and good discount in WORLDWIDE for mutually beneficial long-term relationship. We try our best to support our distributors and business partners to develop more market percentage. Please join us, let’s create the glorious future together! You can add my MSN: jolie1985love@live.cn or Skpye: shenkeyun2 Wantai Electrical Appliance Co., Ltd http://www.wantmotor.com Contact: Jolie Shen TEL: 0086-519-85138377 Mobile: 0086-13775076288 MSN: jolie1985love@live.cn Skype: shenkeyun2 E-mail: sales@wantmotor.com

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	wantai
MPN	www.wantmotor.com
Model	85BYGH450D-007
