PLX31-MBTCP-MBS4 Our Modbus TCP/IP communication gateways offer bidirectional data transfers between devices on dissimilar networks. Our Modbus TCP/IP Driver uses Multiple Clients and Servers for faster data throughput. Protocol conversion gateways are the ideal solution for distributed networks when adding a remote rack becomes too costly. The PLX30s are stand-alone DIN-rail mounted gateways that provide one Ethernet port for communication, remote configuration and diagnostics, and up to four (4) serial communication ports. The PLX30 gateways also come with an SD Card slot (SD card optional) for storing configuration files. In the event of a failure the SD card can be transferred to another gateway reducing downtime. These gateways contain a 4000 word database, includes a wide input power range (10 Vdc – 36 Vdc), and an extended temperature range (-25°C to 70°C). The PLX30 gateways include all the necessary cables required for communication. Features and Benefits 4000 Word database Status data Node Health 10/100 Mb Ethernet port with Auto Cable Crossover Detection Data Analyzer for Modbus Serial Network Hardware Specification Description Power Supply 24 Vdc nominal 10Vdc to 36 Vdc allowed Positive, Negative, GND Terminals Current Load 24 Vdc @ 300mA nominal 10 to 36 Vdc @ 610mA maximum Operating Temperature -25°C to 70°C (-13°F to 158°F ) Storage Temperature -40°C to 80°C (-40°F to 176°F ) Shock IEC 60068-2-27; 15G @ 11ms, 3-Axis (Operational) IEC 60068-2-27; 30G @ 18ms, 3-Axis (Non-Operational) Vibration IEC 60068-2-6; 5G @ 10Hz to 150Hz Relative Humidity 5% to 95% RH with no condensation Dimensions (Height x Width x Depth) Standard: 5.38 in x 1.99 in x 4.38 in (13.67 cm x 5.05 cm x 11.13 cm) LED Indicators Configuration (CFG) and Error (ERR) Communication Status Power (PWR) and Hardware Fault (FLT) Network Status (NS) EtherNet/IP™ Class I or Class III Connection Status (EtherNet/IP Only) Module Status (MS) Module Configuration Status (EtherNet/IP Only) Ethernet Communication Port Link/Activity and 100mbit Serial Communication Port Receive (RX) and Transmit (TX) Ethernet Port 10/100Mbit half-duplex RJ45 Connector Electrical Isolation 1500 Vrms at 50 Hz to 60 Hz for 60 seconds, applied as specified in section 5.3.2 of IEC 60950: 1991 Ethernet Broadcast Storm Resiliency = less than or equal to 5000 [ARP] frames-per-second and less than or equal to 5 minutes duration Serial Port(S) Note: The number of serial communication ports depends on the gateway type, and the combination of protocols. Serial Port Isolation 2500 Vrms port signal isolation per UL 1577 serial port communication signal uses RF(Radio Frequency) modulation signal as isolation media, IC chip model is SiliconLabs Si844x(Si8440,Si8441,Si8442). Protocols MBS Protocol Specifications MBS Protocol Specifications Protocol Specifications Modbus Master A port configured as a virtual Modbus Master actively issues Modbus commands to other nodes on the Modbus network. The Master ports have an optimized polling characteristic that polls slaves with communication problems less frequently. Command List Up to 100 commands per Master port, each fully configurable for function, slave address, register to/from addressing and word/bit count. Polling of Command List Configurable polling of command list, including continuous and on change of data, and dynamically user or automatic enabled. Status Data Error codes available on an individual command basis. In addition, a slave status list is maintained per active Modbus Master port. Modbus Slave A port configured as a Modbus slave permits a remote Master to interact with all data contained in the module. This data can be derived from other Modbus slave devices on the network, through a Master port, or from the module. Node Address 1 to 247 (software selectable) Status Data Error codes, counters and port status available per configured slave port PLX30-MBTCP Protocol Secifications Protocol Specifications EtherNet/IP® Specifications Number of Class 3 Server Connections 5 Supported PLC Types PLC2, PLC5, SLC, ControlLogix Supported Message Types PCCC and CIP Number of Class 3 Client Connections Connected Unconnected 2 1 Number of Class 1 I/O Connections PLX-31-EIP-MBTCP 2 I/O connection sizes 248/248 Max RPI time 5ms per connection CIP Services Supported 0x4C - CIP Data Table Read 0x4D - CIP Data Table Write Command List Support for 100 commands per Client, each configurable for command type, IP address, register to/from addressing and word/bit count. Command Sets PLC-2/PLC-3/PLC5 Basic Command Set PLC5 Binary Command Set PLC5 ASCII Command Set SLC500 Command Set Modbus TCP/IP Specifications Supported Modbus Function Codes 1: Read Coil Status 2: Read Input Status 3: Read Holding Registers 4: Read Input Registers 5: Force (Write) Single Coil 6: Preset (Write) Single Holding Register 15: Force (Write) Multiple Coils 16: Preset (Write) Multiple Holding Registers 22: Mask Write Holding Register (Slave Only) 23: Read/Write Holding Registers (Slave Only) Supported Clients 10 Supported Servers MBAP Encapsulated 5 5 Command List Up to 160 fully configurable Client commands Status Data Error codes reported individually for each command Command List Polling Each command can be individually enabled or disabled; write-only-on-data-change is available Modbus Serial Specifications Command List Up to 100 commands per Master port, each fully configurable for Function Code, slave address, register to/from addressing and word/bit count. Supported Modbus Function Codes 1: Read Coil Status 2: Read Input Status 3: Read Holding Registers 4: Read Input Registers 5: Force (Write) Single Coil 6: Preset (Write) Single Holding Register 15: Force (Write) Multiple Coils 16: Preset (Write) Multiple Holding Registers 22: Mask Write Holding Register (Slave Only) 23: Read/Write Holding Registers (Slave Only) Software configurable communication parameters Baud rate: 110 baud to 115.2 kbps Parity: None, Even, Odd Data Size: 7 or 8 bits Stop bits: 1 or 2 RTS on/off delay: 0 to 65535 milliseconds Modbus Modes RTU mode (binary) with CRC-16ASCII mode with LRC error checking, Floating point data movement supported including configurable support for Enron and Daniel implementations Polling of Command List Configurable polling of command list, including continuous and on change of data, and dynamically user or automatic enabled. Status Data Error codes available on an individual command basis. In addition, a slave status list is maintained per active Modbus Master port. Node Address 1 to 247 (software selectable) RS Interface RS232, RS422, and RS485
