Protek 6502 20mhz + X1/x10 Probes - Oscilloscopio + Sonde X1/x10

US $300.00

Sutter Creek, California, United States
Feb 14th

Open on mobile:
QR code

20MHz Dual Trace Oscilloscope with Alt-Mag 20MHz Bandwidth Alt-Mag sweep for simultaneous display of main and X5 magnified trace 1mV/Div Vertical sensitivity Alternate trigger for a stable display of unrelated signals X5 Sweep Magnification Large 6 inch CRT with internal graticule, for parallax free measurements Autofocus Internal Sync spearator circuit for stable triggering on video signals Leightweight with low power consumption Supplied with 2 (X1, X10) probes and operating manual Vertical Amplifier (CH 1 and CH 2) Sensitivity 5mV/Div to 5V/Div in 10 steps (1-2-5 seq) X5 Mag: 1mV/Div to 1V/Div Accuracy ±3% (5% in X5 Mag) Bandwidth (-3dB) DC to 20MHz Rise Time < 17.5ns Input Impedance 1MW + 25pF Input Coupling AC-Gnd-DC Invert Channel CH2 Display Modes CH1, CH2, Add, Dual Chop Frequency 250kHz ±3% Maximum Input Voltage 400V (DC or AC peak) CH1 Signal Output 20mV/Div into 50W: (50Hz to 5MHz) Horizontal Sweep Sweep Time 0.1µs/Div to 0.2s/Div in 20 steps (1-2-5 seq) X5 Mag: 20ns/Div to 40ms/div Accuracy ±3% (±5% in X5 Mag) Display Mode A, Alt-Mag, XY Sweep Magnifier X5 ±5% Trace Sep 1.5 Div Min Horizontal Amplifier Linearity ±3% (±5% in X5 Mag) X-Y Mode CH 1-X axis, CH 2-Y axis Sensitivity Same as CH 1 Vertical Amplifier Bandwidth (-3dB) DC to 500kHz Phase Error ? 3° DC to 50kHz Triggering Modes Auto, Norm, TV-V, TV-H Source CH 1, CH 2, Line, EXT Coupling AC Slope Positive or Negative Trigger Sensitivity Int: DC to 2MHz: 2 Div 2MHz to 20MHz: 3 Div Ext: DC to 2MHz: 200mV P-P; 2MHz to 20MHz: 300mV P-P TV Synch: Int: 1 Div Min; Ext: 1 V P-P Min TV-H (Television Line synchronizing Freq) TV-V (Television Frame synchronizing Freq) Automatically switched by the A Time/Div Front panel control External Trigger Input Input Impedance: 1 MW+ 20pF Maximum Input Volts: 300V (DC or AC peak) Z Axis Modulation Sensitivity 5V P-P (Intensity increases with a negative going input) Bandwidth (-3dB) DC to 2MHz Input Impedance Approx. 33 KW Maximum Input Voltage 30V (DC or AC peak) Calibrator Signal Frequency Approx. 1kHz (±20%) Voltage 0.5V P-P ±3% Duty Cycle Approx. 50% CRT Type 6" rectangular CRT with illuminated internal 8 X 10 Div graticule (1 Div = 1cm) Acceleration Voltage 2kV General Specification Power Requirements AC Input Voltage: 100V, 120V, 220V, 240V ±10% selectable Frequency 50/60Hz Power Consumption 35W Operating Temperature 0 to 40°C DIMensions 5.5" H x 13.4" W x 14.8" D Weight 24 lbs. Supplied Accessories Manual, AC Power cord, (2) X1/X10 Probes
