Protek B-801 Function Generator, Sine,square,triangle, Works Great!

US $115.00

  • Seattle, Washington, United States
  • Jan 29th
Open on mobile:
QR code
Protek B-801 2Mhz Function Generator You are bidding on a good, fully function Protek Function Generator. What you see is EXACTLY what you will get. Performance Characteristics of the Protek B-801 Output Characteristics Waveforms Sine, Square, Triangle, Pulse, Ramp Frequency Range 0.02Hz to 2MHz in 7 ranges Tuning Range 100:1 on each range Frequency Accuracy B801: 5% of FS Frequency Stability 0.1% after 20 minutes Amplitude 2V to 20V P-P open circuit DC Offset Variable from < -10V to > +10V open circuit Output Impedance 50W ±5% Variable Symmetry 1:1 to 4:1 Output Attenuation 0 to 40dB (20dB ±1dB step and 0 to 20dB variable) VCF Input 100:1 tuning range with an input voltage level from 0 to -10V Sine Wave Distortion < 2% from 10Hz to 100kHz Amplitude Flatness ? 0.3dB Square Wave Rise/Fall Time < 100ns at max amplitude Triangle Wave Linearity > 98% to 100kHz Sweep Characteristics Sweep Mode Linear Sweep Time Variable from 20ms to 2s Sweep Width Variable from 10:1 to 1000:1 General Specifications Power Requirements AC Line Voltage: 100/120/220/240V ±10% Frequency: 48Hz to 66Hz Power Consumption Approx. 5VA Operating Temperature 0 to 50°C Size 3.3" H x 8.8" W x 10.1" D Guarantee Terms: This item is guaranteed to power on & has no known functional Issues. If the item does not power on (DOA) or is functionality defective, you may qualify for a refund. In such a case, you must contact me within 30 days. Thanks for looking!
Condition Seller refurbished :
An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes “Fully function, verified, Calibrated, and adjusted to the best possible condition.”
