Prototyping Board Designed To Mate With The Tis Tmdsevm6446 Davinci Dev. Board

US $149.00

  • Providence, Rhode Island, United States
  • Jun 9th
Open on mobile:
QR code
-davinci Important We, Link Research, are the manufacturer of this product. For customers outside of the United States, you are responsible for all customs fees, duty fees and any import fees and taxes. We will only accept returns for a manufacturer's defects. You will be responsible for the shipping cost to ship the board back to us. Under no circumstances will we accept for return a board that has been used (items soldered to it). Adapter board chip carriers and chips shown in image are not included.  Schematic is included with purchase. If you are not sure about something, please ask before you buy! Product Description The model LR-DAVPROTO1-S1 is a general purpose, stackable prototyping board designed to mate with the Texas Instruments' TMDSEVM6446 DaVinci video development board. The board is 9"x5.75", providing a generous area for custom prototyping work. An array of holes (0.035" diameter) on 0.1" spacing will accommodate thru-hole devices, as well as SMT adapters from companies such as Aries, Ironwood, etc. Between the gridded holes are buss traces with holes every half-inch or so. These holes fall in between the gridded holes, so as not to disrupt the continuous grid of 0.1" spaced holes. The ability to stack an additional board on top of this board allows multi-board prototype systems to be developed. For added value, six RCA jacks and four 3.5mm headphone jacks are included on the left edge of the board. These connectors are brought out to labeled holes on the prototyping board for easy wiring to any custom circuit the user may have. At the ends of the buses are white writing pads, which can be used for buss labeling. A fine-point Sharpie pen is included with each prototyping board.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Link Research
Country/Region of Manufacture United States
Model DaVinci Prototype
MPN LR-DAVPROTO1-S1
