Prova 5601 Clamp-on Ground Resistance Tester new

US $345

Killeen, Texas, United States
Jan 29th

Open on mobile:
QR code

This item is brand new in case never used. Non-Contact Ground Resistance Measurement No Auxiliary Electrode Needed Jaw Diameter ? 23 mm (5601) Jaw Diameter ? 35 mm(5637) 0.025 – 1500 Ohm 0.2mA– 30A(5601)0.2mA– 35A(5637),True RMS 116 Sets of Memory(5601,5637) Programmable Hi and Lo Alarm(5601,5637) Programmable Data Logging (5601,5637) Telecommunication Cable TV system Electrical Power Plant Cellular Phone System Factory and Facility Gas Station Tank Ground Resistance (Auto range) Range Resolution Accuracy of Reading 1,2 0.025 - 0.250 ? 0.002 ? ± 1.5% ± 0.05 ? 0.250 - 1.000 ? 0.02 ? ± 1.5% ± 0.05 ? 1.001 - 9.999 ? 0.02 ? ± 1.5% ± 0.1 ? 10.00 - 50.00 ? 0.04 ? ± 2.0% ± 0.3 ? 50.01 - 99.99 ? 0.04 ? ± 2.0% ± 0.5 ? 100.0 - 200.0 ? 0.4 ? ± 3.0% ± 1.0 ? 200.1 - 400.0 ? 2 ? ± 5.0% ± 5 ? 400.1 - 600.0 ? 5 ? ± 10% ± 10 ? 600.1 - 1500 ? 20 ? ± 20% 1 Loop resistance noninductive, external field < 200 A/m, external electrical field < 1 V/m, conductor centered. 2 Resistance Measurement Frequency: 1.667KHz,3.333KHz(optional) Ground/Leakage Current (Auto range, 50/60 Hz, True RMS, Crest Factor < 3.5) Range Resolution Accuracy of Reading 0.200 - 1.000 mA 0.001 mA ± 2.0% ± 0.05 mA 1.00 - 10.00 mA 0.01 mA ± 2.0% ± 0.03 mA 10.0 - 100.0 mA 0.1 mA ± 2.0% ± 0.3 mA 100 - 1000 mA 1 mA ± 2.0% ± 3 mA 0.20 - 4.00 A 0.001A ± 2.0% ± 0.03A 4.00 - 30.00 A(5601) 0.01A ± 3.0% ± 0.03A 4.00 - 35.00 A(5637) 0.01A ± 3.0% ± 0.03A General Specification Accuracy of Resistance Calibration Plate ±0.5% Data Logging Capacity 116 records Data Logging Interval 1 to 255 seconds Conductor Size 35mm /1.38”(5637), 23mm /0.90”(5600,5601) Jaw Opening 38mm /1.49”(5637), 27mm /1.06”(5600,5601) Battery Type 9V IEC 6 LR61 (Alkaline) Display Type 4 digits 9999 counts LCD Overload Indication OL Battery Life 3000 measurements Low Battery Indication Range Selection Auto Power Consumption 40mA Sampling Time 0.5 seconds Operating Temperature 0 °C to 50 °C (14 °F to 122 °F ) Operating Humidity: Less than 85% RH Storage Temperature -20 °C to 60 °C (-4 °F to 122 °F ) Storage Humidity: Less than 75% RH Dimension( 5637 276mm (L) x 100mm(W) x 47mm(H),10.8" (L) x 3.9"(W) x 1.9"(H) Dimension( 5600,5601 ) 257mm (L) x 100mm(W) x 47mm(H),10.1" (L) x 3.9"(W) x 1.9"(H) Weight( 5637) 750g/1.65lbs Weight( 5600,5601) 640g/1.41lbs Accessories Resistance Calibration Plate x 1 Battery 9V (Installed) x 1 Carrying Box x 1 Users Manual x 1
