PTFE Sanitary Tri-Clamp Screen Gasket, White - 3" w/ 4 Mesh (316L Stainless), US $169.36 – Picture 0

PTFE Sanitary Tri-Clamp Screen Gasket, White - 3" w/ 4 Mesh (316L Stainless), US $169.36 – Picture 1

Ptfe Sanitary Tri-clamp Screen Gasket, White - 3" W/ 4 Mesh (316l Stainless)

US $169.36

Wilmington, Delaware, United States
Jan 30th

Open on mobile:
QR code

A Division of Vertex Industries, Inc. Home About Us Contact Us Shipping & Returns Catalog Line Card Tech Info Clamps Compression Fittings Gaskets Hangers & Supports Hose Instrumentation Pipe Fittings Pipe Sight Glasses Steam Specialties Tools Tube Fittings Tubing Valves PTFE Sanitary Tri-Clamp Screen Gasket, White - 3" w/ 4 Mesh (316L Stainless) Click images to enlarge. Specifications Description All PTFE & Tuf-Steel® Gaskets w/ 100 Mesh Screens include a 10 Mesh backing screen to support the 100 Mesh against the flow. Note: The following options are available as special order for these gaskets: metal detectable elastomers, special screen materials (Hastelloy, Membrane Inserts, PTFE), larger diameters, and finer meshes. Let us know your custom requirements and we will be happy to quote them for you. Rubber Fab's PTFE Tri-Clamp® Screen Gaskets are interchangeable with standard Tri-Clamp® Sanitary Gaskets for ease of use. These fluid filtration gaskets feature a 316L stainless steel screen, making them suitable for high purity systems. The screens are available in a variety of mesh sizes ranging from 4 Mesh up to 100 Mesh. Fluid filtration gaskets provide the most comprehensive range of stainless steel mesh and filter cloth to provide the ultimate particulate elimination for protecting fill and finish sterile products. All Rubber Fab Screen Gaskets feature Dutch Twill weave which provides for maximum strength and minimum pressure drop. PTFE Sanitary Tri-Clamp® Screen Gaskets are the material of choice where low temperature flexibility and hygienic seal memory are not required. We don't recommend using PTFE Sanitary Gaskets where large temperature variations frequently occur because the affect on the PTFE's density makes joints more prone to leakage. With that said we recommend using high pressure clamps to help negate the affects of any temperature fluctuations. PTFE gaskets provide excellent heat resistance, second only to Tuf-Steel®, with an operating range from -100°F to 500°F. From a chemical standpoint PTFE has good stability, almost no extractables, a low absorption rate, and excellent resistance to process fluids. These Tri-Clamp® Gaskets can remain in service for long periods of time in both water and steam applications. Storing PTFE Screen Gaskets: Shelf Life: 20 Years from cure date Store in original packaging in clean and dry warehouse Do not expose to direct sunlight Keep more than 6' away from electric motors Maintain temperature between 65°F and 85°F PTFE Gasket Standards Compliance:FDA CFR 21, 177.1550 U.S. Pharmacopeia Class VI Certification USDA Hazard Analysis and Critical Control Points Cytotoxicity Criteria USDA and 3-A Sanitary Standards ASME-BPE Standards for Type I and Type II ADI Free® (Animal Derived Ingredient Free) Current Good Manufacturing Practices (CGMP) PTFE Tri-Clamp® Screen Gasket Features:Color Code: No Dot -100°F to 500°F Temperature Range Excellent heat resistance Almost no extractables Low absorption rate Excellent resistance to process fluids Good stability 316L Stainless Steel Mesh Dutch Twill Weave Pattern Interchangeable with standard Tri-Clamp® Gaskets 1 = Excellent 2 = Good 3 = Acceptable 4 = Marginal 5 = Poor 6 = Do Not Use Continuous Stream Intermittent Steam Pure Water Ambient Pure Water Hot Process Fluids Ambient Process Fluids Hot Process Fluid Variables 0°-100°C Temperature Range Tuf-Steel® 1 1 1 1 1 1 1 -350°-550°F Tuf-Flex® 1 1 1 1 1 1 1 -20°-300°F Food-Flex® 1 1 1 1 1 1 1 -30°-250°F PTFE 1 1 1 1 1 1 3 -100° to 500°F Silicone (platinum) 2 2 2 2 2 2 1 -40°-450°F Silicone (peroxide) 2 2 2 2 2 2 1 -40°-450°F FKM 3 2 2 2 2 2 2 -30°-400°F EPDM (peroxide) 3 3 3 3 3 3 3 -30°-300°F Buna 0 0 5 5 5 5 5 -30°-200°F Screen Gasket Reference Chart Mesh Size Wires/Inch Approx. Micron Retention Opening Size % Open Area Filter Cloth Mesh Filter Cloth Thickness 4 x 4 5156 0.203" 65.90% -- -- 6 x 6 3340 0.110" 62.40% -- -- 8 x 8 2464 0.097" 60.20% -- -- 10 x 10 1905 0.075" 56.30% -- -- 12 x 12 1532 0.060" 52.40% -- -- 14 x 14 1306 0.051" 51.80% -- -- 16 x 16 1130 0.045" 50.70% -- -- 18 x 18 979 0.039" 48.20% -- -- 20 x 20 864 0.034" 46.20% -- -- 24 x 24 703 0.028" 44.10% -- -- 30 x 30 516 0.020" 37.20% -- -- 40 x 40 381 0.015" 36.00% -- -- 50 x 50 318 0.013" 30.30% -- -- 60 x 60 233 0.009" 30.30% -- -- 80 x 80 160 0.007" 31.40% -- -- 100 x 100 140 0.006" 30.30% -- -- 120 x 120 118 0.005" 30.90% -- -- 150 x 150 103 0.004" 37.20% -- -- -- 96 -- -- 20 x 200 0.033" 180 x 180 80 0.003" 34.30% -- -- 200 x 200 74 0.002" 33.60% -- -- -- 70 -- -- 120 x 180 0.010" -- 65 -- -- 120 x 200 0.009" 250 x 250 61 0.002" 36.00% -- -- -- 50 -- -- 120 x 330 0.010" 325 x 325 43 0.001" -- -- -- -- 40 -- -- 120 x 400 0.009" -- 35 -- -- 120 x 500 0.009" -- 30 -- -- 120 x 600 0.009" -- 25 -- -- 200 x 600 0.006" -- 21 -- -- 200 x 830 0.006" -- 10 -- -- 200 x 1150 0.006" About Us Since 2002 Austenitex has been a value added distributor of process and industrial stainless steel pipe, tubing, components, and equipment. With a staff possessing many years of experience in engineering, design, construction, and maintenance, Austenitex has become a leader in the industry. We provide procurement and fulfillment services for one point of accountability. If you have special requirements, we can provide custom fabrication services. We can prepare submittal and turnover documentation to your specifications. We offer bagging and tagging services so that material is released to you by your drawing. Kitting, valve tagging, custom labeling, and special packaging services are also available. Our goal is to be a strategic partner to your operation. Our clientele appreciate the extra effort we expend to ensure they receive the correct product for their application, on time, at a competitive price. When you need it now and it has to be right, Austenitex is your solution! Shipping Terms We ship daily Monday - Friday and make every effort to ensure that your order is shipped the same or next business day of receiving your cleared payment. We reserve the right to combine shipments that are shipping to the same address. All of our products are shipped by either UPS or USPS with tracking information provided. The method displayed on this listing may be subject to change under certain circumstances. If you require expedited delivery services please contact us. International Orders We are happy to serve customers from all over the world. We gladly ship our eBay orders to Canada, Europe, Australia and New Zealand. Please contact us for a shipping quote. If you aren't in one of those countries, please contact us at (877) 304-3165. Please note that customs forms will be filled out as "merchandise" using your actual sale price as the value. We're not a great fan of customs taxes, but unfortunately it's illegal to try to avoid them. We hope you'll understand. Please contact your local post office or customs office to estimate potential customs charges to import our items from the USA. Feedback & Returns If anything at all is not as you had anticipated, please contact us, we are here to help! We will gladly leave positive feedback for our customers and we appreciate the same. If there is an error on our part, we will replace the goods at our expense. Please be sure to note your eBay Item ID number, eBay User Name and First and Last name in your email. Also save all original tags, packaging, and paperwork in preparation for return. Contact Us If you have a question, require special assistance, can't find what you are looking for, or would like to place a custom order please contact us by email or at (877) 304-3165. We are available from Monday - Friday 8AM - 5PM EST to assist you! We do our best to respond to emails within 1-2 business days. If you have a time sensitive matter, please call us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	UPC	2014-11-18T06:06:58Z
EAN	2014-11-19T00:31:49Z
