PTH12010WAS 12V in 15A out switching regulator (surface mount), US $13.00 – Picture 0
PTH12010WAS 12V in 15A out switching regulator (surface mount), US $13.00 – Picture 0

Pth12010was 12v In 15a Out Switching Regulator (surface Mount)

US $13.00

  • Athens, Attiki, Greece
  • Mar 4th
Open on mobile:
QR code
Description The PTHxx010Y are a series of ready-to-use switching regulator modules from Texas Instruments designed specifically for bus termination in DDR and QDR memory applications. Operating from either a 3.3-V, 5-V or 12-V input, the modules generate a VTT output that will source or sink up to 15 A of current (12 A for 12-V input) to accurately track their VREF input. VTT is the required bus termination supply voltage, and VREF is the reference voltage for the memory and chipset bus receiver comparators. VREF is usually set to half the VDDQ power supply voltage. Both the PTHxx010Y series employs an actively switched synchronous rectifier output to provide state-of-the-art stepdown switching conversion. The products are small in size (1.37 in x: 0.62 in), and are an ideal choice where space, performance, and high efficiency are desired, along with the convenience of a ready-to-use module. Operating features include an on/off inhibit and output over-current protection (source mode only). The on/off inhibit feature allows the VTT bus to be turned off to save power in a standby mode of operation. To ensure tight load regulation, an output remote sense is also provided. Package options include both throughhole and surface mount configurations. Features VTT Bus Termination Output (Output Tracks the System VREF) 15 A Output Current (12 A for 12-V Input) 3.3-V, 5-V or 12-V Input Voltage DDR and QDR Compatible On/Off Inhibit (for VTT Standby) Under-Voltage Lockout Operating Temp: –40 to +85°C Efficiencies up to 91 % Output Overcurrent Protection (Non-Latching, Auto-Reset) 62 W/in? Power Density Safety Agency Approvals: UL/cUL60950, EN60950, VDE Point-of-Load Alliance (POLA™) Compatible
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Texas Instruments
Country of Manufacture Malaysia
Model PTH12010WAS
