Punchsim Nc Punch G-code Editor + Simulator For Amada Cnc Turret Punch Press

US $49.95

Canada, Canada
May 11th

Open on mobile:
QR code

You are bidding on one computer license of PunchSim v6.3 software. PunchSim is a G-code editor and simulator capable of graphically previewing how a program will be punched on an Amada CNC punch press. Create or edit a G-code file and view the changes before sending the program to the control. Check your part by measuring the distance between tool hits on the screen. Zoom in for a better view of all punch hits including nibbling and micro-joints. Slow down the simulation speed for an easier view of the exact punching sequence. Automatically find which tool hits are produced by a particular line in the G-code file. Get automatic G-code help while typing and error checking during simulation. These are only some of the features of PunchSim. Machine operators can preview and get valuable information on their next job. Visually verify clamp interference, micro-joints, repositioning, punching sequence, etc. Programmers can create and verify G-code files or just check the NC code created by a CAM system before sending it to the shop floor. Can you confirm that your CAM system actually generated the G-code sequence exactly as you wanted? No more surprises from the shop floor. You can verify everything in your office computer beforehand. Ever wanted to know how long the next program will take to punch? The Punch Estimation Report includes total time, total tool hits, number of tool changes, and total distance traveled, for your program. Improve operator efficiency and reduce machine setup time. No need for a scientific calculator any more, the included Math Expression Calculator is easy to use and is all you will ever need for programming. Use the Bend Deduction Calculator to help program a flat part more quickly and accurately. Correct flat layouts mean less time with costly corrections and less scrap parts. Want to know the tonnage required for a punch in a particular material? The included Punch Force Calculator will do that in a snap. Includes DNC serial communication function to send G-code files to the machine control using the Com Port. Want to be a programmer? This is a terrific tool for anybody wanting to learn to create Gcode programs. Not having access to a machine can make it very difficult to test your programs when trying to learn. PunchSim is like having access to a machine anytime and without the fear of breaking anything. This is why several technical schools in Europe and America use it in their classrooms. Some features include: Support for standard tooling: Round, Square, Rectangle, SingleD, DoubleD, Obround, Special Automatic G-code help while typing Basic G-code error checking User defined machine properties Each tool simulated in different color Each G-code line is highlighted as it is simulated Variable simulation speed Zooming functions Optional trace line between hits Print Gcode or simulation screen Measure between tool hits in simulation Total tool hit count during simulation Easily identify tool hits produced by a single G-code line Machine Punch Time Estimation report Math Expression Calculator Bend Deduction Calculator Punch Force Calculator Send files to your machine using the included DNC serial communication function Supports standard Amada® G-codes (Aries, Vela, Coma, Pega, Vipros, AC, AE, EM, etc) Supports both Inch and Metric And much more PunchSim Demo - YouTube Video will open in a new window [isdntekvideo] Don't spend hundreds or even thousands of dollars on generic software. PunchSim is specifically designed for Amada turret punch presses. PunchSim is currently being used in technical schools, sheet metal shops, and by programmers in the office and at home. PunchSim is compatible with Windows 7/8/10 Some Buyer comments: "Works very well, Great product Thanks" -bakeair "Very useful software with excellent utilities. Great addition to my tools!" -tpproducts "Excellent transaction, very good Ebayer thank you very much from Munich, Germany" -cncmechanik "Smooth transaction i recommend" -stephane_quevillon "perfekt ! Danke !!!!!!" -fhammann "OK No problem" -jassind "Super EBAYER would deal with again" -pete2808 "very good respond and help I will greatly recomend it" -rocimtech "good help in downloading program quick response time" -pwondras "very good" -garyk8371 "Great" -elginsfather "Is very good simulator" -mike020715 "Well communicated, Thanks A+++" -nodrogiednoc "A good transaction! Thanks!" -snow02 "thank's again good for student" -cnc-canada "Great item, very fast shipping" -armfab "great program thanks again!" -mytiant "good stuff" -signconsumables "A+" -bear981 "Great cust. service, exceptional communication, Thank U" -james_mueller "Awesome! Immediate response! A++++++++++ Thanks!" -biodomage "Great product will buy again!" -mytiant "Great program, easy to use! Thanks! Highly reccommend seller!" -crissybill "OK PERFECT+++++++++++++++++DA ITALY" -gianff "Very useful software with excellent utilities. Great addition to my tools!" -tpproducts "GOOD COMMUNICATION QUICK SHIPMENT SUPER EBAYER A+++++++++++++" -scoutoso "One-of-a-kind product, great communication. Would do business with again!" -wacojosh CLICK HERE TO SEE ALL OF OUR LISTINGS Visit us at CNCSOFT.COM for more info

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Brand

CNCsoft
